Gas Pressure Switch, DG Series, 0.4–500 mbar Range, EU Certified

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 150BG 6K2 is a gas pressure switch rated for use with positive, negative, and differential gas and air pressure applications within the specified ranges. This device features an adjustable switching point via a setting dial and operates with media such as gas, air, and flue gases. The DG series represents the European version of this product.

Key features include:

• Pressure range: 0.4 to 500 mbar (0.16 to 200 "WC)
• Pneumatic connections: Internal Rp 1/8" (2x), Rp 1/4" (2x)
• Contact options: Silver contacts (24–250V AC, 0.05–5A) or gold contacts (5–250V AC, 0.01–5A)
• Electrical connection: Screw terminals with M16x1.5 cable gland or optional 4-pin plug and socket
• Certifications: EU certified, AGA approved, EAC approved
• Construction is silicon-free
