Gas Pressure Switch - DG Series, Adjustable, 0.4-500 mbar

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 50SG 6K2 is a gas pressure switch rated for use with positive gas and air pressures, as well as negative and differential air pressures. This product is part of the DG series, which includes both European (DG) and US (DG..T) versions, each with specific certifications and connection options. The switch includes a setting dial to adjust the switching point within specified parameters and is constructed without silicon components.

Key features include:

• Monitors positive gas/air pressure; also compatible with negative/differential air/flue gases within specified ranges
• Includes a setting dial to adjust the switching point within specified parameters
• Available in European version (EU certified, AGA, EAC approved) or US version (UL Listed, FM Approved)
• Pressure range: 0.4 to 500 mbar (European), 0.2 to 200" WC (US)
• Pneumatic connections: Internal Rp 1/8", Rp 1/4" (European); Internal Rp/NPT threads available on US models
• Electrical contacts: Silver or gold; supports various voltage/amperage ranges up to max 250V AC/5A depending on model
• Multiple electrical connection types including screw terminals with cable gland/conduit or plug-and-socket options
