Gas Pressure Switch – DG Series, Adjustable, EU/US Versions

The HONEYWELL KROMSCHRODER SW,PRESS,GAS,DG 500HG 3 is a gas pressure switch rated for monitoring positive, negative, and differential gas or air pressures within specified parameters. This device includes an integrated setting dial to adjust the switching point within specified limits and operates with various media including gas, air, and flue gases. The DG series includes both European (DG) and US (DG..T) versions to accommodate different regional standards.

Key features:

• Monitors positive, negative, and differential pressures in gas or air systems
• Includes an integrated setting dial to adjust the switching point within specified limits
• Compatible with gas, air, and flue gases under conditions described in the product specifications
• Available in EU-certified/AGA/EAC approved version (DG) or UL/FM listed US version (DG..T)
• Electrical connections include screw terminals with M16x1.5 cable gland or optional 4-pin plug/socket
• Pneumatic connections: Internal Rp 1/8" & Rp 1/4" for DG; NPT options available on DG..T
