Gas Pressure Switch, Diaphragm, 3–500 mbar, DG Series

The HONEYWELL KROMSCHRODER SW,PRESS,DBL,GAS,DG 60/60VC4 6W is a diaphragm gas pressure switch rated for use with positive pressure applications in compatible gases including natural gas, biogas, air, and flue gases. It features a micro switch mechanism that is constructed without silicone components and provides switching point adjustment through a setting dial or is available with factory preset options.

Key features include:

• Pressure range: 3 to 500 mbar (1.2 to 144"WC)
• Pneumatic connections: Internal (1x or 2x Rp 1/4), External (Rp 1/8 or Rp 1/4)
• Electrical connection: Four-pin plug and socket
• Contact types/switching capacity:
  • CE version: Silver contacts (24–250V AC, 0.05–5A); Gold contacts (5–250V AC, 0.01–5A) - UL version: Gold contacts (max. 30V AC, 0.05A); Silver contacts (30–240V AC, up to 5A)
  • Certifications: EU certified; UL listed; FM approved; AGA approved; EAC marked
  • Construction is silicon-free
