Gas Solenoid Valve - NC, 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VAS1T-0/NW is a Class A solenoid valve intended for use in automatic shut-off applications involving gas and air, conforming to EN 161 standards. The valve is normally closed (NC) and opens upon energization, featuring a pilot lamp and flow adjustment capability. It supports a maximum operating pressure of 500 mbar and is rated IP65 for ingress protection. The unit holds EU certification as well as FM and CSA approvals, with certified according to SIL 3 and PL e standards.

Key features include:

• Size range: 1 to 9; nominal diameter (DN) from 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or integrated pressure switches
