Gas Solenoid Valve - VAS120, 500 mbar, IP65, EN 161, Class A Certified

The HONEYWELL KROMSCHRODER VAS120/-R/NWGR is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air, meeting EN 161 standards. The valve is configured to be closed when not energized and includes a pilot lamp and adjustable flow settings. It operates at a maximum pressure of 500 mbar, has an IP65 rating for ingress protection, and holds EU certification as well as FM and CSA approvals. The unit is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
