Gas Solenoid Valve - VAS225, 500 mbar, IP65, Auto Shut-Off, Class A

The HONEYWELL KROMSCHRODER VAS225/-R/NW is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air. This valve remains closed when de-energized and rated for operation up to a maximum pressure of 500 mbar. It is equipped with a pilot lamp, flow adjustment mechanism, and has an IP65 ingress protection rating. The unit is certified to EU standards, FM and CSA approved, and compatible with systems specified as SIL 3 or PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
