Pressure Switch - Adjustable, Air/Flue Gas, 0.12–20"WC

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 50AG 61 is an A/C pressure switch rated for use with air and flue gas pressure measurement applications. It supports positive, negative, and differential pressure measurements within a range of -1.5 to 150 mbar (0.12 to 20"WC). The switching point can be adjusted via a setting dial, enabling adjustment of the switching point within specified parameters for use with air, flue gas, or non-aggressive gases.

Key features include:

• Adjustable switching point using a setting dial
• Pressure range: -1.5 to 150 mbar (0.12 to 20"WC)
• Compatible media: Air, flue gas, non-aggressive gases
• Tube connections available; CE versions with Rp 1/4 or Rp 1/8 threads; UL versions with 1/4" NPT or 1/8" NPT threads
• Contact options: Silver contacts (24–250V AC, up to 5A) and gold contacts (varied voltage/amperage ratings depending on version)
• Screw terminals with M16x1.5 cable gland or optional screw terminals with a 1/2" NPT conduit
• Certified by EU, UL listed; FM and AGA approved; EAC and RoHS compliant
• Silicon-free construction
