Pressure Switch - Air/Flue Gas, Adjustable, 1.5-150 mbar

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 3,5KT 3 is an A/C pressure switch rated for use in applications involving air and flue gas pressure measurement. It is compatible with positive, negative, and differential pressure measurement within specified ranges when used with air, flue gas, or non-aggressive gases. The device includes an adjustable switching point via a setting dial as per product specifications.

Key features include:

• Pressure range: -1.5 to 150 mbar (0.12 to 20"WC)
• Pneumatic connections: CE versions with Rp 1/4 and Rp 1/8; UL versions with 1/4" NPT and 1/8" NPT
• Contact options: Silver contacts (24–250V AC, 0.05–5A) or gold contacts (5–250V AC, 0.01–5A) for CE; silver contacts (30–240V AC, 5A) or gold contacts (max 30V AC, 0.05A) for UL
• Electrical connection: Screw terminals with M16x1.5 cable gland or screw terminals with a 1/2" NPT conduit; includes a four-pin plug and socket
• Certifications: EU certified, UL listed, FM approved, AGA approved
• Construction is silicon free
