Pressure Switch - Air/Flue Gas, Adjustable, DL 24KG 3

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 24KG 3 is an A/C pressure switch rated for use in applications involving air and flue gas pressure measurement. It supports positive, negative, and differential pressure measurements in systems using air, flue gas, or non-aggressive gases. The device features a switching point adjustment via a setting dial to allow adjustment of the switching point within the specified range.

Key features include:

• Pressure range: -1.5 to 150 mbar (0.12 to 20"WC)
• Pneumatic connections: CE versions with Rp 1/4 and Rp 1/8; UL versions with 1/4" NPT and 1/8" NPT
• Contact options: Silver contacts (24–250V AC, 0.05–5A) or gold contacts (5–250V AC, 0.01–5A) for CE; silver contacts (30–240V AC, 5A) or gold contacts (max 30V AC, 0.05A) for UL
• Electrical connection: Screw terminals with M16x1.5 cable gland or screw terminals with a 1/2" NPT conduit; includes a four-pin plug and socket
• Certified by EU standards, UL listed, FM approved, AGA approved; RoHS compliant
• Silicon-free construction
