Pressure Switch - Air/Flue Gas, Adjustable, DL 8KT 1

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 8KT 1 is an A/C pressure switch rated for use in applications involving air and flue gas pressure measurement. It supports positive, negative, and differential pressure measurements in systems using air, flue gas, or non-aggressive gases. The switching point can be adjusted via a setting dial to accommodate specific system requirements.

Key features include:

• Pressure range: -1.5 to 150 mbar (0.12 to 20"WC)
• Pneumatic connections: CE versions with Rp 1/4 and Rp 1/8; UL versions with 1/4" NPT and 1/8" NPT
• Electrical contacts: Silver or gold options available for both CE (24–250V AC, up to 5A) and UL (30–240V AC up to 5A; gold max 30V AC at 0.05A) versions
• Electrical connection: Screw terminals with M16x1.5 cable gland or 1/2" NPT conduit; includes a four-pin plug/socket
• Certified by EU, UL listed, FM approved, AGA approved
• Silicon-free construction
