Pressure Switch - Air/Flue Gas, Adjustable, DL Series

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 2EH 1 is an A/C pressure switch rated for use in applications involving air and flue gas pressure measurement. It supports positive, negative, and differential pressure measurements within specified ranges when used with air, flue gas, or other non-aggressive gases. The switching point is adjustable via a screw mechanism; refer to product specifications for adjustment parameters.

Key features include:

• Certified with EU certification, UR listing, FM approval, AGA approval; RoHS compliant
• Adjustable switching point through adjustment screw
• Compatible media: Air, flue gas, non-aggressive gases
• Pressure range (model dependent): DL1-50E: 0.2–50 mbar (0.08–20" WC); DL2/4/14/35E: 30–3500 Pa (0.12–14.1" WC)
• Tube pneumatic connections
• Electrical contacts available in silver or gold; various voltage/amperage ratings depending on version (CE or UL)
• Electrical connection via 6.3x0.8 AMP connectors (UR recognized)
• Silicon-free construction
