Pressure Switch for Air/Flue Gas, Adjustable, -1.5–150 mbar

The HONEYWELL KROMSCHRODER SW,PRESS,AIR,DL 24KT 1 is an A/C pressure switch rated for use in applications involving air and flue gas pressure measurement. It is compatible with positive, negative, and differential pressures within the specified range when used with air, flue gas, or non-aggressive gases. The device includes an adjustable switching point via a setting dial as specified by product documentation.

Key features include:

• Pressure range: -1.5 to 150 mbar (0.12 to 20"WC)
• Tube connections: Rp 1/4 and Rp 1/8 (CE versions); 1/4" NPT and 1/8" NPT (UL versions)
• Contact options: Silver contacts (24–250V AC, 0.05–5A CE; 30–240V AC, 5A UL) or gold contacts (5–250V AC, 0.01–5A CE; max 30V AC, 0.05A UL)
• Electrical connection: Screw terminals with M16x1.5 cable gland or 1/2" NPT conduit
• Includes a four-pin plug and socket
• Certified by EU authorities; listed by UL; approved by FM and AGA
• RoHS compliant construction
• Silicon-free design
