Pressure Switch - Gas/Air, Adjustable, DG & DG..T Models

The HONEYWELL KROMSCHRODER Kromschroder pressure switch is a device rated for use with positive gas and air pressures, as well as negative and differential air pressures. It includes an adjustable setting dial for switching point selection and operates with media such as gas, air, and flue gases. The product is available in two versions: the DG (European version) and the DG..T (US version), each available with specified certifications, connection types, and electrical specifications.

Key features include:

• Includes an adjustable setting dial for switching point selection
• Compatible with gas, air, and flue gases within the specified pressure ranges
• European model (DG): Range of 0.4 to 500 mbar (0.16 to 200 "WC"), internal Rp 1/8" or Rp 1/4" pneumatic connections; silver contacts rated at 24–250V AC/0.05–5A; gold contacts rated at 5–250V AC/0.01–5A; screw terminals or M16x1.5 cable gland electrical connections
• US model (DG..T): Range of 0.2 to 200" WC; internal Rp 1/4" NPT or 1/8" NPT pneumatic connections; silver contacts up to max 240V AC/5A; gold contacts up to max 30V AC/DC/0.05A; screw terminals with M16x1.5 cable gland or optional locking/manual reset
