Solenoid Gas Safety Valve - 500 mbar, IP65, SIL 3 Rated

The HONEYWELL KROMSCHRODER VAS350/-F/NWGL is a Class A solenoid gas safety valve intended for use as a shut-off valve in gas and air systems. It operates with a maximum pressure of 500 mbar and is configured to be closed when not energized. The unit features a pilot lamp, flow adjustment, and an IP65-rated enclosure. It holds certification meeting the requirements of SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
