Solenoid Gas Safety Valve – Class A, EN 161, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS1-/15R/NWGR is a Class A solenoid gas safety valve intended for use as an automatic shut-off valve in gas and air systems. This valve conforms to EN 161 standards, is normally closed when de-energized, and is rated for a maximum operating pressure of 500 mbar. It includes an integrated pilot lamp and adjustable flow settings, with an ingress protection rating of IP65. The unit holds EU certification as well as FM and CSA approvals, and is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Operation modes: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicators, visual indicators, fitted bypass/pilot gas valves, or fitted pressure switches
