Solenoid Valve for Gas/Air, 500 mbar, IP65, EN 161 Certified

The HONEYWELL KROMSCHRODER VAS115/-R/NQ is a Class A solenoid valve intended for use in applications requiring the automatic shut-off of gas and air, conforming to EN 161 standards. This valve remains closed when de-energized and is rated for operation at a maximum pressure of 500 mbar. It includes a pilot lamp and adjustable flow settings, with an ingress protection rating of IP65. The unit holds EU certification as well as FM and CSA approvals, and it is certified for use in systems up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
