Solenoid Valve for Gas/Air, 500 mbar, IP65, EN 161

The HONEYWELL KROMSCHRODER VAS340R/NKGL is a Class A solenoid valve intended for use in applications requiring automatic shut-off of gas and air, operating according to EN 161 standards. The valve is configured to be in a closed position when not energized and features a pilot lamp and flow adjustment. It is rated for operation at pressures up to 500 mbar and certified according to EU, FM, CSA, SIL 3, and PL e standards. The enclosure has an IP65 rating.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions with position indicator, visual indicator, fitted bypass/pilot gas valve, or pressure switches
