Solenoid Valve for Gas/Air, Normally Closed, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VLV ASY, SOLND, NORMALLY CLSD, NAT, LP, AIR, 2 is a solenoid valve intended for use in applications requiring the control of gas and air. This valve operates in a normally closed position when de-energized and meets Class A requirements to EN 161 standards. It is rated for operation at pressures up to 500 mbar and includes pilot lamp indication and flow adjustment. The unit is IP65 rated for ingress protection and holds EU certification as well as FM and CSA approvals.

Key features include:

• Size range: 1 to 9; DN (nominal diameter): 10 to 125
• Connection options: threaded or flanged
• Operation types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available with position indicator/visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches DG../VC
• Certified for use in systems up to SIL 3 and PL e
