Solenoid Valve - Gas Shut-Off, 100mm ISO Flange, 500 mbar
Mfr # KS88204968
Zoro # G715296405
Specifications
Product Information
Details
Description
The HONEYWELL KROMSCHRODER VAS8100F0 is a solenoid valve intended for use in applications requiring automatic shut-off of gas and air. Classified as a Class A valve to EN 161 standards, it operates in a normally closed position when de-energized and supports maximum operating pressures up to 500 mbar. This model features ISO flange connections, size: 100 mm, provides adjustable flow settings, and contains a pilot lamp that indicates operational status. It holds EU certification along with FM and CSA approvals, and is certified for use in systems up to SIL 3 and PL e.
Key features:
- Valve size: SZ 8 (DN range: 10 to 125)
- Connection type: ISO flange (100 mm)
- Operating pressure: Up to 500 mbar
- Electrical connection: Terminal; available mains voltages include 24 V DC, 120 V AC, or 230 V AC
- Opening/closing options: Quick opening/quick closing or slow opening/quick closing
- Enclosure rating: IP65
- Additional options available such as position indicator, visual indicator, fitted bypass/pilot gas valve, or fitted pressure switches
