This item is Discontinued.

Hubbell Wiring Device-Kellems 30A/125V INLINE L5-30 LOCKING AUTO GFPIL30125LKA

30A/125V INLINE L5-30 LOCKING AUTO (Discontinued)

Mfr # GFPIL30125LKA
Zoro # G400701504

Get a 10% off coupon

Free 30-day returns

Get 30 days to pay with Net 30

Real support from real people

Specifications

Product Information

MFR #

GFPIL30125LKA

Zoro #

G400701504

UPC #

783585692142

Country of Origin

China

Dimensions

Outside Diameter

0.335

Conductor Size

#10 AWG

Details

Item

Industrial Grade

Voltage Rating

120 VAC

Color

Yellow

Jacket Material

PVC

Type

Portable, Locking

Style

Automatic Set

Application

Line Cord with Devices

Insulating Material

Elastomer

Conductor Type

Copper

Connectivity

Plug-In

Construction

Fabricated

Weight

2.25 lb

Brand

Hubbell Wiring Device-Kellems

Amperage

30 A

Standard

UL Listed

UPC

783586000000

Current Rating

30 A

Number Of Conductors

Series

Extra Heavy Duty

Nema Rating

L5-30

Number of Strands

Multi

Temp. Rating

-35 Degrees C to 66 Degrees C (-30 Degrees F to 150 Degrees F)

Industry Standard(s)

UL Listed

Strands

Multi

Temperature Rating

-35 Degrees C to 66 Degrees C (-30 Degrees F to 150 Degrees F)

Material - Insulation

Elastomer

Performance

Electrical - Dielectric Withstand - 1500 VRMS across contact, 4000 VRMS between conductors & enclosure Electrical - Operating Voltage Range - 85% to 110% Electrical - Rated Voltage - 120V AC, 240V AC, 120/240V AC, 3Ø 250V AC, 3Ø 120/208V AC Electrical - Surge Withstand - 6000V impulse, 0.5 ms rise time 100kHz ringing frequency Environmental - Construction - Industrial grade design Environmental - Housing Rating - UL Type 4X Environmental - Leakage Current - At 93% Humidity leakage current is zero Environmental - Operating Temperature - -35°C to 66°C, -30°F to 150°F. Environmental - Type - Meets UL943 Class A GFCI

Voltage Rating Description

120 VAC

OEM Brand Name

Hubbell Wiring Device-Kellems

Amperage Rating

30 A

Material - Jacket

PVC

Current / Amperage Rating

30 A

Item Type

Industrial Grade

Description

Hubbell Wiring Device Kellems, GFCI Cordset, Inline, Locking, 30A 125VAC, 2-Pole 3-Wire Grounding, L5-30, Auto Set
