  11. Cable Connector, 1/2 in., Straight, Black
Hubbell Wiring Device-Kellems Cable Connector, 1/2 in., Straight, Black SHC2024CR - main

Cable Connector, 1/2 in., Straight, Black

  • Mfr # SHC2024CR

  • Zoro # G0369817

product price: $10.35
/ea

Key Features

Material
Nylon
Box Connection
1/2 in MNPT
Insulated
Yes
Number of Cords
1
Cord Dia. Range
0.50 in to 0.62 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SHC2024CR
Zoro #
G0369817
UPC #
783585451664
Country of Origin
United States

Dimensions

Cord Dia. Range
0.50 in to 0.62 in
Min. Throat Dia.
0.58"
Hub Trade Size
1/2"
Length
2.03"
Length - Box to End of Connector
1 1/2 in
Length - External Strain Relief
No External Strain Relief
Hub Size
1/2 in MNPT
Compatible Conduit Trade Size
1/2 in
Form Size
F2
Thread Size
1/2 in
Overall Length
2 in
Dimension D
.58" (14.7) Throat Dia.
Dimension B
1.50" (38.1) Ref.
Dimension E A/C
1.25" (31.7)
Cord Diameter Range
.500"- .625" (12.7- 15.8)
Dimension C
.53" (13.5)
Dimension A
1.32" (33.5) Dia.
Recommended Knockout Hole Size
.86"- .91" (21.8-23.0)
Dimension E A/F
1.12" (28.4)
Display Size
1/2" NPT

Details

Item
Liquid Tight Cord Connector
Material
Nylon
Box Connection
1/2 in MNPT
Insulated
Yes
Number of Cords
1
Connector Type
Straight
Strain Relief Type
No External Strain Relief
Male/Female
Male
Gland Color Code
Brown
Hazardous Location Rating
Class I, Division 2, Class II, Division 1 & 2, Class III, Division 1 & 2
Style - Connector
Straight
Item - Cord Connector
Liquid Tight Cord Connector
Body Color - Cord Connector
Black
Liquid Tight / Dust Tight
Liquid Tight
Color
Black
Material - External Strain Relief
No External Strain Relief
Material - Cord Connector
Nylon
Standards
CSA Certified, Title 46-Part 111, UL 514B, United States Coast Guard Approval
For Use With
Kellems Wire Management
Maximum Operating Temperature
225 Degrees F
Resistance Properties
Corrosion Resistant
Minimum Operating Temperature
-30 Degrees F
NEMA Rating
NEMA 12, NEMA 13, NEMA 4, NEMA 4X
Connection Orientation
Straight
For Maximum Cable OD
0.63 in
IP Rating
IP66
Body Material
Nylon
Liquid Tight
Yes
Compatible Conduit Type
Liquid Tight Cord Connector
For Minimum Cable OD
0.5 in
Body Color
Black
Environmental Rating
Not Flammable, Hazardous Locations
Thread Gender
Male
Collar Material
Nylon
Bushing Material
Neoprene
Thread Type
NPT Thread
Grommet Color Code
Brown
Hazardous Locations
Hubbell cord connectors are suitable for use in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class III Div. 1 & 2 N.E.C. Reference 501-4(b), 502-4(a), 502-4(b), 503-3(a), and 503-3(b).
Flammability
Hubbell nylon cord connectors have a UL 94-V2 rating.
Certifications
UL Listed in accordance with Standard 514B, CSA Certified, United States Coast Guard Approval, Title 46-Part 111.
Color Code
Brown
Cord Connector Body Style
Straight Male
Product Type
Cord Connectors
Material/Style
Nylon Standard Style
Application
Straight Male- Form 2
Series
Standard Duty
Industry Standard(s)
UL Listed
Performance
Environmental - Flammability - UL 94-V2 Environmental - Hazardous Locations - Used in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class Ill Div. 1 & 2 in accordance with the NEC Environmental - Operating Temperatures - -30°F to +225°F (-34°C to +107°C)
Type
Straight Male
Environmental Conditions
Suitable For Use In Wet Locations When Used With A Listed Nylon Washer Between Box And Fitting.
Number Of Conductors
Single
Item Type
Cord Connectors
Temperature Rating
Minimum -30 Deg F to 225 Deg F (-34 Deg C to 107 Deg C)
Conductor Range
0.5-0.63 in (12.7-15.9 mm)
OEM Brand Name
Hubbell Wiring Device-Kellems
Material - Mounting Hardware
Locknut or Tapped Opening

Description

Liquid Tight Cord Connector, Cord Dia. Range 0.50 in to 0.62 in, Box Connection 1/2 in MNPT, Material - Cord Connector Nylon, External Strain Relief Material No External Strain Relief, Gland Color Code Brown, Body Color - Cord Connector Black, Number of Cords 1, Style - Connector Straight, Strain Relief Type No External Strain Relief, External Strain Relief Length No External Strain Relief, Length - Box to End of Connector 1 1/2 in, Insulated Yes
