Hubbell Wiring Device-Kellems Cable Connector, 3/4 In, Straight, Black SHC2037CR - main

Cable Connector, 3/4 In, Straight, Black

  • Mfr # SHC2037CR

  • Zoro # G1213213

product price: $9.86
/ea

Key Features

Material
Nylon
Box Connection
3/4 in MNPT
Hub Trade Size
3/4"
Min. Throat Dia.
0.77"
Style - Connector
Straight
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SHC2037CR
Zoro #
G1213213
UPC #
783585451725
Country of Origin
United States

Dimensions

Hub Trade Size
3/4"
Min. Throat Dia.
0.77"
Length
2.15"
Cord Dia. Range
0.63 in to 0.75 in
Length - External Strain Relief
No External Strain Relief
Length - Box to End of Connector
1 5/8 in
Hub Size
3/4 in MNPT
Overall Length
2 1/8 in
Compatible Conduit Trade Size
3/4 in
Form Size
F3
Thread Size
3/4 in
Dimension B
1.60" (40.6) Ref.
Dimension D
.77" (19.6) Throat Dia.
Dimension C
.55" (14.0)
Dimension A
1.56" (39.6) Dia.
Dimension E A/C
1.44" (36.6)
Recommended Knockout Hole Size
1.09"- 1.14" (27.8-29.0)
Cord Diameter Range
.625"- .750" (15.8- 19.0)
Dimension E A/F
1.31" (33.3)
Display Size
3/4" NPT

Details

Item
Liquid Tight Cord Connector
Material
Nylon
Box Connection
3/4 in MNPT
Style - Connector
Straight
Body Color - Cord Connector
Black
Material - External Strain Relief
No External Strain Relief
Standards
CSA Certified, Title 46-Part 111, UL 514B, United States Coast Guard Approval
Number of Cords
1
Gland Color Code
Yellow
Hazardous Location Rating
Class I, Division 2, Class II, Division 1 & 2, Class III, Division 1 & 2
Color
Black
Liquid Tight / Dust Tight
Liquid Tight
Insulated
Yes
Strain Relief Type
No External Strain Relief
Material - Cord Connector
Nylon
Item - Cord Connector
Liquid Tight Cord Connector
Male/Female
Male
Connector Type
Straight
For Use With
Kellems Wire Management
Application
Straight Male- Form 3
Thread Gender
Male
For Minimum Cable OD
0.63 in
Collar Material
Nylon
NEMA Rating
NEMA 12, NEMA 13, NEMA 4, NEMA 4X
Liquid Tight
Yes
Environmental Rating
Not Flammable, Hazardous Locations
Minimum Operating Temperature
-30 Degrees F
Body Color
Black
IP Rating
IP66
Connection Orientation
Straight
Compatible Conduit Type
Liquid Tight Cord Connector
For Maximum Cable OD
0.75 in
Thread Type
NPT Thread
Grommet Color Code
Yellow
Body Material
Nylon
Maximum Operating Temperature
225 Degrees F
Bushing Material
Neoprene
Resistance Properties
Corrosion Resistant
Product Type
Cord Connectors
Color Code
Yellow
Flammability
Hubbell nylon cord connectors have a UL 94-V2 rating.
Hazardous Locations
Hubbell cord connectors are suitable for use in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class III Div. 1 & 2 N.E.C. Reference 501-4(b), 502-4(a), 502-4(b), 503-3(a), and 503-3(b).
Cord Connector Body Style
Straight Male
Material/Style
Nylon Standard Style
Certifications
UL Listed in accordance with Standard 514B, CSA Certified, United States Coast Guard Approval, Title 46-Part 111.
Industry Standard(s)
UL Listed
Environmental Conditions
Suitable For Use In Wet Locations When Used With A Listed Nylon Washer Between Box And Fitting.
Type
Straight Male
Conductor Range
0.63-0.75 in (15.9-19.0 mm)
Number Of Conductors
Single
Performance
Environmental - Flammability - UL 94-V2 Environmental - Hazardous Locations - Used in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class Ill Div. 1 & 2 in accordance with the NEC Environmental - Operating Temperatures - -30°F to +225°F (-34°C to +107°C)
Material - Mounting Hardware
Locknut or Tapped Opening
OEM Brand Name
Hubbell Wiring Device-Kellems
Series
Standard Duty
Item Type
Cord Connectors
Temperature Rating
Minimum -30 Deg F to 225 Deg F (-34 Deg C to 107 Deg C)

Description

Liquid Tight Cord Connector, Cord Dia. Range 0.63 in to 0.75 in, Box Connection 3/4 in MNPT, Material - Cord Connector Nylon, External Strain Relief Material No External Strain Relief, Gland Color Code Yellow, Body Color - Cord Connector Black, Number of Cords 1, Style - Connector Straight, Strain Relief Type No External Strain Relief, External Strain Relief Length No External Strain Relief, Length - Box to End of Connector 1 5/8 in, Insulated Yes
