  11. Cord Connector, 1 in., Straight, Gray
Hubbell Wiring Device-Kellems Cord Connector, 1 in., Straight, Gray FHC1043 - main

Cord Connector, 1 in., Straight, Gray

  • Mfr # FHC1043

  • Zoro # G2349685

product price: $54.14
/ea

Key Features

Material
Aluminum
Box Connection
1 in MNPT
Connector Type
Straight
Standards
CSA Certified, Title 46-Part 111, UL 514B, United States Coast Guard Approval
Color
Gray
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
FHC1043
Zoro #
G2349685
UPC #
783585203430
Country of Origin
United States

Dimensions

Hub Trade Size
1"
Length - Box to End of Connector
2 5/16 in
Length
2.30"
Length - External Strain Relief
No External Strain Relief
Cord Dia. Range
0.88 in to 1.00 in
Min. Throat Dia.
1.10"
Hub Size
1 in MNPT
Compatible Conduit Trade Size
1 in
Thread Size
1 in
Form Size
F4
Recommended Knockout Hole Size
1.36"- 1.41" (34.5-35.7)
Cord Diameter Range
.88"- 1.00" (22.2- 25.4)
Dimension B
2.30" (58.4) Ref.
Dimension A
1.75" (44.5) Dia.
Dimension D
1.10" (27.9) Throat Dia.
Dimension C
.88" (22.4)
Dimension E A/F
1.63" (41.4)
Dimension E A/C
1.88" (47.8)

Details

Item
Liquid Tight Cord Connector
Material
Aluminum
Box Connection
1 in MNPT
Connector Type
Straight
Standards
CSA Certified, Title 46-Part 111, UL 514B, United States Coast Guard Approval
Color
Gray
Material - External Strain Relief
No External Strain Relief
Item - Cord Connector
Liquid Tight Cord Connector
Liquid Tight / Dust Tight
Liquid Tight
Strain Relief Type
No External Strain Relief
Body Color - Cord Connector
Silver
Insulated
No
Hazardous Location Rating
Class I, Division 2, Class II, Division 1 & 2, Class III, Division 1 & 2
Material - Cord Connector
Aluminum
Gland Color Code
Gray
Number of Cords
1
Male/Female
Male
Style - Connector
Straight
For Use With
Kellems Wire Management
Environmental Rating
Hazardous Locations
Liquid Tight
Yes
Body Color
Silver
Minimum Operating Temperature
-30 Degrees F
Connection Orientation
Straight
Thread Gender
Female
Collar Material
Aluminum
Maximum Operating Temperature
225 Degrees F
Thread Type
NPT Thread
Grommet Color Code
Gray
Body Material
Aluminum
Compatible Conduit Type
Liquid Tight Cord Connector
Color Code
Gray
Flammability
Hubbell nylon cord connectors have a UL 94-V2 rating.
Hazardous Locations
Hubbell cord connectors are suitable for use in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class III Div. 1 & 2 N.E.C. Reference 501-4(b), 502-4(a), 502-4(b), 503-3(a), and 503-3(b).
Material/Style
Aluminum
Cord Connector Body Style
Straight Female
Certifications
UL Listed in accordance with Standard 514B, CSA Certified, United States Coast Guard Approval, Title 46-Part 111.
Product Type
Cord Connectors
Effective Operating Temperature
-30°F to +225°F (-34°C to +107°C)

Description

Liquid Tight Cord Connector, Cord Dia. Range 0.88 in to 1.00 in, Box Connection 1 in MNPT, Material - Cord Connector Aluminum, External Strain Relief Material No External Strain Relief, Gland Color Code Gray, Body Color - Cord Connector Silver, Number of Cords 1, Style - Connector Straight, Strain Relief Type No External Strain Relief, External Strain Relief Length No External Strain Relief, Length - Box to End of Connector 2 5/16 in, Insulated No
