  11. Duplex Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded
Hubbell Wiring Device-Kellems Duplex Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded HBL5260SA - main

Duplex Straight Blade Receptacle, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded

  • Mfr # HBL5260SA

  • Zoro # G1265126

product price: $70.15
/ea

Key Features

Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL5260SA
Zoro #
G1265126
UPC #
783585060019
Country of Origin
China

Dimensions

Display Size
Standard
Face Plate Width
1.3 in
Face Plate Height
2.6 in
Overall Depth
4 in
Mount Hole Center-to-Center Height
3.3 in

Details

Item
Duplex Straight Blade Receptacle
Receptacle Type
Duplex
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Side
Grounding
Grounded
Housing Color
Blue
Mount Type
Flush
Standards
CSA C22.2 No. 42, UL 498
Flange Type
Non-Flanged
HP
1/2 hp
Surge Suppression
Yes
Outlet Type - Plugs and Receptacles
Decorator Duplex
Wiring Method - Plugs and Receptacles
Side
Voltage
125VAC
Sub-Category
Duplex Receptacles
Outlet Type
Decorator
Weather Resistant
No
Mounting Type - Plugs and Receptacles
Flush
Tamper Resistant
No
Power Indicator
Yes
Material
Composite
Weather Resistant - Plugs and Receptacles
No
Mounting Type
Flush
Number of Gangs
1
NEMA Receptacle Configuration - Plugs and Receptacles
5-15R
Application Environment
Commercial
Corrosion Resistant
No
NEMA Configuration
5-15
Color
Blue
Outlet
Straight Blade
Connectivity
Terminal Screws
Indicator Type
None
Mounting Hardware Material
Mounting Screws
Carton Quantity
10
Operating Temperature
32 Deg F to 140 Deg F (0 Deg C to 60 Deg C)
Type
Duplex
Amperage
15 A
Application
Decorator Duplex
Response Time
5
Frequency
60 Hz
Nema Rating
5-15R
Series
Specification Grade
Brand
Hubbell Wiring Device-Kellems
Environmental Rating
Indoor Dry Unless Protected By Additional Means
NEMA Enclosure Rating
1
Horsepower Rating
1/2 hp
UL 94 Flammability Rating
V-2
AFCI
No
Connection Orientation
Straight
Polarized
Yes
Shrouded
No
Cover Type
No Cover
Includes
Grounding Staple, Mounting Hardware
Grade
Federal Specification
Visual Indicator Lights
Power Connected
Surge Protection
Yes
For Location
Indoor
GFCI
No
Maximum Operating Temperature
140 Degrees F
Contact Material
Brass
Housing Material
Composite
Market
Commercial
Minimum Operating Temperature
32 Degrees F
Includes Mounting Hardware
Yes
Contact Design
Tandem Modified Bypass
LED
Red
Device Base
Nylon
ANSI/IEEE
C62.41 (IEEE 587)
Terminal Screws
#8-32 Brass
Certifications
UL Listed File E2186
Installation Categories
A (Ring Wave), "B" (Unidirectional Impulses)
Listed To:
UL Standards 498 Receptacles, Meets UL1449 TVSS
Mounting Screws
Steel, Zinc-Plated
Device Top
Nylon
Mounting Strap
.050" (1.3) Steel-Zinc Coated
Clamping Plate
.031" (.8) Brass
Receptacle Style
Duplex
CSA Certified
To Specification C22.2 No. 42
Receptacle Grade
Standard
Grounding Screw
Steel (Green)
Poles and Wires
2 Pole, 3 Wire
Auto Ground Clip
Stainless Steel
Power Contact
.031" (.8) Brass

Description

The HUBBELL 15A Duplex Decorator Receptacle 125VAC 5-15R BL is a duplex receptacle intended for indoor use, with integrated surge protection. It features two internal metal oxide varistors (MOVs) that are rated at 240 joules of surge suppression per mode and includes a nylon component shield to protect the circuit board from contaminants. The device has a power-on indicator light and an audible alarm to indicate when surge protection is no longer active.


Key Features of the HUBBELL 15A Duplex Decorator Surge Protection Receptacle:

  • Surge Suppression: Integrated MOV technology rated at 240 joules of surge suppression per mode

  • Visual Indicator: Power-on LED confirms power availability

  • Audible Alarm: Indicates when the device's surge protection function is inactive

  • NEMA Configuration: 5-15R, compatible with standard straight blade plugs

  • Amperage/Voltage Rating: Rated for 15 A, 125 VAC operation

  • Grounding: Includes automatic self-grounding staple and grounding screw

  • Material Construction: Nylon device base/top with composite housing; brass contacts and clamping plate

  • Mounting Type: Flush mount with included mounting hardware

  • Circuit Board Protection: All-glass conformally coated PCB
