Shop HUBBELL WIRING DEVICE-KELLEMS

Extra Heavy Duty Industrial Grade, Toggle Switches, General Purpose AC, Double Pole, 20A 120/277V AC, Back and Side Wired Toggle

  • Mfr # HBL1222BK

  • Zoro # G900701332

product price:
$
36.95
/ea

Key Features

Switch Type
Double Pole
Color
Black
Width
1.31 in
Type
Toggle
Voltage
120/277V AC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
HBL1222BK
Zoro #
G900701332
UPC #
783585189109
Country of Origin
China

Dimensions

Width
1.31 in
Height
1.87 in
Length
4.06 in
Dimensions
4.06 in x 1.31 in x 1.87 in
Wire Size
#14 AWG to #10 AWG

Details

Switch Type
Double Pole
Color
Black
Type
Toggle
Voltage
120/277V AC
Style
Double Pole
Connectivity
Back and Side Wired
Dielectric Strength
Withstands 1500V AC minimum for 1 minute
Current Rating
20 A
Number Of Poles
Double Pole
Carton Quantity
10
Amperage
20 A
Voltage Rating
120-277 VAC
Temp. Rise
30°C maximum at rated current
Series
Extra Heavy Duty
Application
Back and Side Wired
Temperature Rise
30°C maximum at rated current
Operating Temperatures
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Switch Handle Positions
2
Wiring Style
Back and Side Wired
Dielectric Voltage
Withstands 1500V AC minimum for 1 minute
Product Type
Toggle-switches
Operating Temperature
Max. continuous: 75°C; Min. continuous: -40°C without impact
Max. Continuous Current
20A
Max. Working Voltage
277V AC
Listing and Certifications
Listed to Standard UL 20, CSA Certified, Meets NEMA WD1
Terminal Accommodations
#14 AWG min. - #10 AWG max. solid and stranded copper wire only
Toggle Color
Black
Flammability
UL 94V-2
Switch Grade
Industrial
Overload
Minimum 4.8 times rated current for 100 cycles
Temperature Rise - Max.
30°C maximum at rated current
Performance
Electrical - Dielectric Voltage - Withstands 1500V AC minimum for 1 minute Electrical - Max. Continuous Current - 20A Electrical - Max. Working Voltage - 277V AC Electrical - Overload - Minimum 4.8 times rated current for 100 cycles Electrical - Temperature Rise - 30°C maximum at rated current Environmental - Flammability - UL 94V-2 Environmental - Operating Temperature - Max. continuous: 75°C, Min. continuous: -40°C without impact Mechanical - Terminal Accommodations - #14 AWG min. - #10 AWG max. solid and stranded copper wire only
Amperage Rating
20 A
Current / Amperage Rating
20 A
Voltage Rating Description
120-277 VAC
Industry Standard(s)
UL Listed

Description

Hubbell Wiring Device Kellems, Switches and Lighting Controls,Industrial Grade, Toggle Switches, General Purpose AC, Double Pole,20A120/277V AC, Back and Side Wired, Black
