  11. Flanged Locking Receptacle, L2-20R, 20 A, 250V AC, Single Phase, 2 Pole, Flush Mount, Black
Hubbell Wiring Device-Kellems Flanged Locking Receptacle, L2-20R, 20 A, 250V AC, Single Phase, 2 Pole, Flush Mount, Black HBL3226 - main

Flanged Locking Receptacle, L2-20R, 20 A, 250V AC, Single Phase, 2 Pole, Flush Mount, Black

  • Mfr # HBL3226

  • Zoro # G2843653

product price: $50.95
/ea

Key Features

NEMA Receptacle Configuration
L2-20R
Current Rating
20 A
Voltage Rating
250V AC
Phase
Single
Number of Poles
2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL3226
Zoro #
G2843653
UPC #
783585236292
Country of Origin
United States

Dimensions

Maximum Wire Size
10 AWG
Minimum Wire Size
16 AWG
Wire Size
#12 AWG

Details

Item
Flanged Locking Receptacle
NEMA Receptacle Configuration
L2-20R
Current Rating
20 A
Voltage Rating
250V AC
Phase
Single
Number of Poles
2
Number of Wires
2
Wire Connection Type
Screw Terminals
Shrouded
No
Grounding
Non-Grounded
Housing Color
Black
Mount Type
Flush
Cover Type
No Cover
IP Rating
IP20
NEMA Enclosure Rating
12, 4X
Standards
Federal Specification W-C-596, UL 498
Resistance Properties
Heat Resistant
Flange Type
Flanged
Wiring Style
Standard
Special Features
With Stainless Steel Plate
Material
Cast aluminum
Mounting Type
Flush Mount
Grade
Industrial
Includes
Mounting Screws
For Environment
Dry
Flange Material
Stainless Steel
Horsepower Rating
2 hp
Minimum Operating Temperature
-40 Degrees F
For Location
Indoor
Market
Industrial
AFCI
No
Flange Shape
Round
Number of Gangs
1
Includes Mounting Hardware
Yes
Maximum Operating Temperature
167 Degrees F
Contact Material
Brass/Bronze
Connection Orientation
Straight
Housing Material
Stainless Steel
Polarized
Yes
Flammability
UL 94 VO for Receptacles and Inlets. HB or better for Plugs and Connectors.
Spring Material
.032" (.8) Bronze
Lock Type
Twist-lock
Terminal Designations
Terminals identified in accordance with UL 498
Amps
20

Description

Flanged Locking Receptacle, Connection Orientation Straight, Current Rating 20 A, Flange Shape Round, Flange Type Flanged, Housing Color Black, Housing Material Stainless Steel, Mount Type Flush, NEMA Enclosure Rating 1, NEMA Receptacle Configuration L2-20R, Number of Gangs 1, Number of Poles 2, Number of Wires 2, Phase Single, Polarized Yes, Shrouded No, Voltage Rating 250V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, AFCI No, Contact Material Brass/Bronze
