  8. Industrial Grade, MotorQuick Disconnect Switches, Unfused Switch, Three Pole, 30A 600V AC, With 2) Pre-Wired LINKOSITY Receptacles

This item is Discontinued.

Hubbell Wiring Device-Kellems Industrial Grade, MotorQuick Disconnect Switches, Unfused Switch, Three Pole, 30A 600V AC, With 2) Pre-Wired LINKOSITY Receptacles HBLDS3MQR2

Industrial Grade, MotorQuick Disconnect Switches, Unfused Switch, Three Pole, 30A 600V AC, With 2) Pre-Wired LINKOSITY Receptacles (Discontinued)

  • Mfr # HBLDS3MQR2
  • Zoro # G100702467
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBLDS3MQR2
Zoro #
G100702467
UPC #
783585310947
Country of Origin
United States

Dimensions

Width
6 in
Height
4.12 in
Length
8.5 in
Wire Size
#14 AWG to #10 AWG
Dimensions
8.5 in x 6 in x 4.12 in
Display Size
Standard Sized Product

Details

Item
Disconnect Switch
Phase
Three Phase
Enclosure Type
Type 4X
Amps
30 A
Operating Temperatures
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Listing and Certifications
cUL US Listed
Product Type
motorquick-tn
MotorQuick Item
Type 4X Enclosure
MotorQuick Style
Enclosure with LINKOSITY Female and Male Receptacle
Material - Mounting Hardware
Screw Mounting
Industry Standard(s)
Listed to UL 2238 and UL 50E UL 508, Industrial Control Equipment File #E36355
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
Load Capacity
Inductive
Ingress Protection
IP67
Horsepower - Maximum
15
Environmental Conditions
Indoor and Outdoor
Connectivity
Pre-Wired
Series
MotorQuick/LINKOSITY
OEM Brand Name
Hubbell Wiring Device-Kellems
Wattage
18000
Type
Disconnect Switches
Operating Cycles
10,000 Cycles Minimum
Performance
Electrical - Dielectric Voltage - 2,200V AC minimum for 1 minute Electrical - Electrical Life - 6,000 cycles with load Electrical - Max. Working Voltage - 600V AC RMS Environmental - Flammability - UL94-5VA and V0 Classification Environmental - Operating Temperature - Max. continuous 75°C, Min. continuous -40°C Mechanical - Impact Resistance - UL746C Mechanical - Mechanical Life - 10,000 minimum cycles Mechanical - Terminal Accommodations - 30A, #14 AWG Min. - #10 AWG Max Mechanical - Terminal Torque - 30A, 20 inch pounds
Dielectric Strength
2,200V AC minimum for 1 minute

Description

Hubbell Wiring Device Kellems, Switches and Lighting Controls,Industrial Grade, MotorQuick Disconnect Switches, Unfused Switch, ThreePole, 30A 600V AC, Screw Terminals, Gray, With 2) Pre-Wired LinkosityFemaleReceptacle
