Shop HUBBELL WIRING DEVICE-KELLEMS

Liquid Tight Connector, 1/2 in., Brown

  • Mfr # SHC1024CR

  • Zoro # G2230986

product price:  $10.69
/ea

Key Features

Material
Nylon
Box Connection
1/2 in MNPT
Length
2-1/32"
Body Color - Cord Connector
Silver
Length - External Strain Relief
No External Strain Relief
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
SHC1024CR
Zoro #
G2230986
UPC #
783585208060
Country of Origin
China

Dimensions

Length
2-1/32"
Length - External Strain Relief
No External Strain Relief
Conduit Size
1/2"
Length - Box to End of Connector
1 1/2 in
Cord Dia. Range
0.50 in to 0.63 in
Hub Size
1/2 in
Form Size
F2
Thread Size
1/2 in
Overall Length
2 1/16 in
Compatible Conduit Trade Size
1/2 in
Recommended Knockout Hole Size
.86"- .91" (21.8-23.0)
Dimension D
.58" (14.7) Throat Dia.
Dimension A
1.32" (33.5) Dia.
Dimension E A/F
1.12" (28.4)
Dimension B
1.50" (38.1) Ref.
Cord Diameter Range
.50"- .63" (12.7- 15.9)
Dimension E A/C
1.25" (31.7)
Dimension C
.53" (13.5)
Display Size
1/2" NPT

Details

Item
Liquid Tight Cord Connector
Material
Nylon
Box Connection
1/2 in MNPT
Body Color - Cord Connector
Silver
Hazardous Location Rating
Class I, Division 2, Class II, Division 1 & 2, Class III, Division 1 & 2
Item - Cord Connector
Liquid Tight Cord Connector
Connector Type
Straight
Gland Color Code
Brown
Standards
CSA LR27378, UL E54218(M)
Material - Cord Connector
Nylon
Style - Connector
Straight
Color
Brown
Strain Relief Type
No External Strain Relief
Material - External Strain Relief
No External Strain Relief
Insulated
Yes
Number of Cords
1
For Use With
Kellems Wire Management
For Maximum Cable OD
0.63 in
Maximum Operating Temperature
225 Degrees F
For Minimum Cable OD
0.5 in
Resistance Properties
Corrosion Resistant
Grommet Color Code
Brown
Body Color
Gray
Bushing Material
Neoprene
Connection Orientation
Straight
Liquid Tight
Yes
NEMA Rating
NEMA 12, NEMA 13, NEMA 4, NEMA 4X
Collar Material
Nylon
IP Rating
IP66
Compatible Conduit Type
Liquid Tight Cord Connector
Body Material
Nylon
Environmental Rating
Not Flammable, Hazardous Locations
Thread Type
NPT
Minimum Operating Temperature
-30 Degrees F
Thread Gender
Male
Cord Connector Body Style
Straight Male
Hazardous Locations
Hubbell cord connectors are suitable for use in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class III Div. 1 & 2 N.E.C. Reference 501-4(b), 502-4(a), 502-4(b), 503-3(a), and 503-3(b).
Effective Operating Temperature
-30°F to +225°F (-34°C to +107°C)
Product Type
Cord Connectors
Material/Style
Nylon Standard Style
Color Code
Brown
Certifications
UL Listed in accordance with Standard 514B, CSA Certified, United States Coast Guard Approval, Title 46-Part 111.
Flammability
Hubbell nylon cord connectors have a UL 94-V2 rating.
Performance
Environmental - Flammability - UL 94-V2 Environmental - Hazardous Locations - Used in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class Ill Div. 1 & 2 in accordance with the NEC Environmental - Operating Temperatures - -30°F to +225°F (-34°C to +107°C)
Type
Straight Male
Temperature Rating
Minimum -30 Deg F to 225 Deg F (-34 Deg C to 107 Deg C)
Series
Standard Duty
Material - Mounting Hardware
Locknut or Tapped Opening
Application
Straight Male- Form 2
Number Of Conductors
Single
Industry Standard(s)
UL Listed
Environmental Conditions
Suitable For Use In Wet Locations When Used With A Listed Nylon Washer Between Box And Fitting.
Item Type
Cord Connectors
OEM Brand Name
Hubbell Wiring Device-Kellems
Conductor Range
0.5-0.63 in (12.7-15.9 mm)

Description

Liquid Tight Cord Connector, Cord Dia. Range 0.50 in to 0.63 in, Box Connection 1/2 in MNPT, Material - Cord Connector Nylon, External Strain Relief Material No External Strain Relief, Gland Color Code Brown, Body Color - Cord Connector Silver, Number of Cords 1, Style - Connector Straight, Strain Relief Type No External Strain Relief, External Strain Relief Length No External Strain Relief, Length - Box to End of Connector 1 1/2 in, Insulated Yes, Standards CSA LR27378, UL E54218(M)
