  11. Liquid Tight Connector, 3/4 in., Red
Hubbell Wiring Device-Kellems Liquid Tight Connector, 3/4 in., Red SHC1031 - main

Liquid Tight Connector, 3/4 in., Red

  • Mfr # SHC1031

  • Zoro # G0823873

product price: $9.95
/ea

Key Features

Material
Aluminum
Box Connection
3/4 in MNPT
Cord Dia. Range
0.19 in to 0.25 in
Item - Cord Connector
Liquid Tight Cord Connector
Style - Connector
Straight
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SHC1031
Zoro #
G0823873
UPC #
783585200316
Country of Origin
China

Dimensions

Cord Dia. Range
0.19 in to 0.25 in
Length - Box to End of Connector
1 1/8 in
Length - External Strain Relief
No External Strain Relief
Conduit Size
3/4"
Length
1-5/8"
Hub Size
3/4 in MNPT
Compatible Conduit Trade Size
3/4 in
Thread Size
3/4 in
Overall Length
1 5/8 in
Form Size
F2
Dimension E A/C
1.29" (32.8)
Dimension A
1.13" (28.7) Dia.
Dimension D
.64" (16.3) Throat Dia.
Recommended Knockout Hole Size
1.09"- 1.14" (27.8-29.0)
Dimension C
.55" (14.0)
Cord Diameter Range
.19"- .25" (4.7- 6.3)
Dimension B
1.10" (27.9) Ref.
Dimension E A/F
1.13" (28.7)
Display Size
3/4" NPT

Details

Item
Liquid Tight Cord Connector
Material
Aluminum
Box Connection
3/4 in MNPT
Item - Cord Connector
Liquid Tight Cord Connector
Style - Connector
Straight
Material - Cord Connector
Aluminum
Strain Relief Type
No External Strain Relief
Number of Cords
1
Standards
CSA LR27378, UL E54218(M)
Material - External Strain Relief
No External Strain Relief
Gland Color Code
Red
Insulated
No
Color
Red
Hazardous Location Rating
Class I, Division 2, Class II, Division 1 & 2, Class III, Division 1 & 2
Body Color - Cord Connector
Silver
Connector Type
Straight
For Use With
Kellems Wire Management
Compatible Conduit Type
Liquid Tight Cord Connector
Minimum Operating Temperature
-30 Degrees F
NEMA Rating
NEMA 12, NEMA 13, NEMA 4, NEMA 4X
Connection Orientation
Straight
For Maximum Cable OD
0.25 in
Thread Type
NPT Thread
Body Color
Silver
Bushing Material
Neoprene
Grommet Color Code
Red
Collar Material
Aluminum
IP Rating
IP66
Thread Gender
Male
Maximum Operating Temperature
225 Degrees F
Environmental Rating
Hazardous Locations
Liquid Tight
Yes
For Minimum Cable OD
0.19 in
Body Material
Aluminum
Flammability
Hubbell nylon cord connectors have a UL 94-V2 rating.
Color Code
Red
Material/Style
Aluminum
Cord Connector Body Style
Straight Male
Effective Operating Temperature
-30°F to +225°F (34°C to +107°C)
Hazardous Locations
Hubbell cord connectors are suitable for use in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class III Div. 1 & 2 N.E.C. Reference 501-4(b), 502-4(a), 502-4(b), 503-3(a), and 503-3(b).
Product Type
Cord Connectors
Certifications
UL Listed in accordance with Standard 514B, CSA Certified, United States Coast Guard Approval, Title 46-Part 111.
Number Of Conductors
Single
OEM Brand Name
Hubbell Wiring Device-Kellems
Application
Straight Male- Form 2
Performance
Environmental - Hazardous Locations - Used in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class Ill Div. 1 & 2 in accordance with the NEC Environmental - Operating Temperatures - -30°F to +225°F (-34°C to +107°C)
Type
Straight Male
Temperature Rating
Minimum -30 Deg F to 225 Deg F (-34 Deg C to 107 Deg C)
Material - Mounting Hardware
Locknut or Tapped Opening
Environmental Conditions
Suitable For Use In Wet Locations When Used With A Listed Nylon Washer Between Box And Fitting.
Series
Standard Duty
Conductor Range
0.19-0.25 in (4.7- 6.3 mm)
Item Type
Cord Connectors
Industry Standard(s)
UL Listed

Description

Liquid Tight Cord Connector, Cord Dia. Range 0.19 in to 0.25 in, Box Connection 3/4 in MNPT, Material - Cord Connector Aluminum, External Strain Relief Material No External Strain Relief, Gland Color Code Red, Body Color - Cord Connector Silver, Number of Cords 1, Style - Connector Straight, Strain Relief Type No External Strain Relief, External Strain Relief Length No External Strain Relief, Length - Box to End of Connector 1 1/8 in, Insulated No, Standards CSA LR27378, UL E54218(M)
