  11. Liquid Tight Connector, 3/8 in., Red
Hubbell Wiring Device-Kellems Liquid Tight Connector, 3/8 in., Red SHC1009CR - main

Liquid Tight Connector, 3/8 in., Red

  • Mfr # SHC1009CR

  • Zoro # G0412237

product price: $8.84
/ea

Key Features

Material
Nylon
Box Connection
3/8 in MNPT
Connector Type
Straight
Number of Cords
1
Insulated
Yes
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SHC1009CR
Zoro #
G0412237
UPC #
783585207919
Country of Origin
United States

Dimensions

Length - External Strain Relief
No External Strain Relief
Cord Dia. Range
0.19 in to 0.25 in
Length
1-17/32"
Length - Box to End of Connector
1 1/8 in
Conduit Size
3/8"
Hub Size
3/8 in MNPT
Overall Length
1 9/16 in
Form Size
F1
Compatible Conduit Trade Size
3/8 in
Thread Size
3/8 in
Dimension E A/C
1.00" (25.4)
Dimension B
1.10" (27.9) Ref.
Dimension C
.43" (10.9)
Dimension D
.45" (11.4) Throat Dia.
Recommended Knockout Hole Size
.67"- .70" (17.0-17.8)
Dimension E A/F
.93" (23.6)
Dimension A
1.00" (25.4) Dia.
Cord Diameter Range
.19"- .25" (4.7- 6.3)
Display Size
3/8" NPT

Details

Item
Liquid Tight Cord Connector
Material
Nylon
Box Connection
3/8 in MNPT
Connector Type
Straight
Number of Cords
1
Insulated
Yes
Color
Red
Material - Cord Connector
Nylon
Item - Cord Connector
Liquid Tight Cord Connector
Gland Color Code
Red
Strain Relief Type
No External Strain Relief
Body Color - Cord Connector
Gray
Style - Connector
Straight
Hazardous Location Rating
Class I, Division 2, Class II, Division 1 & 2, Class III, Division 1 & 2
Material - External Strain Relief
No External Strain Relief
Standards
CSA LR27378, UL E54218(M)
For Use With
Kellems Wire Management
Bushing Material
Neoprene
Liquid Tight
Yes
Collar Material
Nylon
For Minimum Cable OD
0.19 in
Maximum Operating Temperature
225 Degrees F
Connection Orientation
Straight
Minimum Operating Temperature
-30 Degrees F
Environmental Rating
Not Flammable, Hazardous Locations
Compatible Conduit Type
Liquid Tight Cord Connector
Body Material
Nylon
IP Rating
IP66
Thread Type
NPT Thread
NEMA Rating
NEMA 12, NEMA 13, NEMA 4, NEMA 4X
Grommet Color Code
Red
For Maximum Cable OD
0.25 in
Thread Gender
Male
Body Color
Gray
Resistance Properties
Corrosion Resistant
Color Code
Red
Hazardous Locations
Hubbell cord connectors are suitable for use in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class III Div. 1 & 2 N.E.C. Reference 501-4(b), 502-4(a), 502-4(b), 503-3(a), and 503-3(b).
Flammability
Hubbell nylon cord connectors have a UL 94-V2 rating.
Cord Connector Body Style
Straight Male
Certifications
UL Listed in accordance with Standard 514B, CSA Certified, United States Coast Guard Approval, Title 46-Part 111.
Effective Operating Temperature
-30°F to +225°F (-34°C to +107°C)
Product Type
Cord Connectors
Material/Style
Nylon Standard Style
OEM Brand Name
Hubbell Wiring Device-Kellems
Temperature Rating
Minimum -30 Deg F to 225 Deg F (-34 Deg C to 107 Deg C)
Series
Standard Duty
Number Of Conductors
Single
Performance
Environmental - Flammability - UL 94-V2 Environmental - Hazardous Locations - Used in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class Ill Div. 1 & 2 in accordance with the NEC Environmental - Operating Temperatures - -30°F to +225°F (-34°C to +107°C)
Environmental Conditions
Suitable For Use In Wet Locations When Used With A Listed Nylon Washer Between Box And Fitting.
Conductor Range
0.19-0.25 in (4.7- 6.3 mm)
Industry Standard(s)
UL Listed
Application
Straight Male- Form 1
Item Type
Cord Connectors
Material - Mounting Hardware
Locknut or Tapped Opening
Type
Straight Male

Description

Liquid Tight Cord Connector, Cord Dia. Range 0.19 in to 0.25 in, Box Connection 3/8 in MNPT, Material - Cord Connector Nylon, External Strain Relief Material No External Strain Relief, Gland Color Code Red, Body Color - Cord Connector Gray, Number of Cords 1, Style - Connector Straight, Strain Relief Type No External Strain Relief, External Strain Relief Length No External Strain Relief, Length - Box to End of Connector 1 1/8 in, Insulated Yes, Standards CSA LR27378, UL E54218(M)
