  11. Locking Receptacle, L15-30R, 30 A, 250V AC, Three Phase, 3 Pole, Flush Mount, White
Hubbell Wiring Device-Kellems Locking Receptacle, L15-30R, 30 A, 250V AC, Three Phase, 3 Pole, Flush Mount, White HBL2726ST - main

Locking Receptacle, L15-30R, 30 A, 250V AC, Three Phase, 3 Pole, Flush Mount, White

  • Mfr # HBL2726ST

  • Zoro # G006171350

product price: $69.19
/ea

Key Features

NEMA Receptacle Configuration
L15-30R
Current Rating
30 A
Voltage Rating
250V AC
Phase
Three
Number of Poles
3
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL2726ST
Zoro #
G006171350
UPC #
783585719214
Country of Origin
China

Dimensions

Overall Depth
2.27 in
Minimum Wire Size
16 AWG
Maximum Wire Size
8 AWG
Face Plate Height
2.77 in
Flange Diameter
2.23 in
Face Plate Width
1.7 in
Mount Hole Center-to-Center Height
3.28 in
Face Diameter
3.06 in

Details

Item
Locking Receptacle
NEMA Receptacle Configuration
L15-30R
Current Rating
30 A
Voltage Rating
250V AC
Phase
Three
Number of Poles
3
Number of Wires
4
Wire Connection Type
Spring Clamp Terminals
Shrouded
No
Grounding
Grounded
Housing Color
White
Mount Type
Flush
Cover Type
No Cover
IP Rating
IP20
NEMA Enclosure Rating
1
Standards
CSA C22.2, Federal Specification W-C-596, UL 498
Resistance Properties
Impact Resistant
Flange Type
Flanged
Features
Accepts Slotted, Phillips, and Robertson Head Drivers
Horsepower Rating
3 hp
Includes Mounting Hardware
Yes
Housing Material
Nylon
Polarized
Yes
Includes
Mounting Hardware
For Environment
Dry
For Location
Indoor
Market
Industrial
AFCI
No
Minimum Operating Temperature
-40 Degrees F
Contact Material
Brass
Maximum Operating Temperature
167 Degrees F
Number of Gangs
1
Connection Orientation
Straight

Description

The HUBBELL Locking Receptacle is a straight, three-phase electrical receptacle suitable for indoor use in industrial settings. It features the EdgeConnectTM screwless termination system, allowing wire insertion and securing via plunger mechanism; does not require additional tools for this process. The device supports backwired terminations with funnel-shaped entries for facilitates installation and accommodates wire sizes from 8 AWG to 16 AWG.


Key Features of the HUBBELL Locking Receptacle:

  • NEMA Configuration: L15-30R; rated for 30 A, 250V AC

  • Number of Poles/Wires: 3 poles, 4 wires; grounded

  • Connection Orientation: Straight; polarized design

  • Contact Material: Brass contacts within an impact-resistant nylon housing

  • Operating Temperature Range: -40°F to 167°F (dry location only)

  • Horsepower Rating: Rated up to 3 hp

  • Includes Mounting Hardware for single-gang installations

  • Certain driver types accepted: Slotted, Phillips, Robertson head drivers compatible with mounting hardware

  • Screwless spring termination is intended to maintain conductor positioning during wiring

  • Covers applicable standards including CSA C22.2, Federal Specification W-C-596, UL 498; UL94 V-2 flammability rating; NEMA Enclosure Type 1/IP20 shrouded construction suitable for indoor use only
