Locking Receptacle, L5-30R, 30 A, 125V AC, Single Phase, 2 Pole, Flush Mount, Screw Terminals
Mfr # IG2610
Zoro # G0850394
product price: $55.45
/eaKey Features
NEMA Receptacle Configuration
L5-30R
Current Rating
30 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
MFR #
IG2610
Zoro #
G0850394
UPC #
783585872308
Country of Origin
United States
Dimensions
Minimum Wire Size
16 AWG
Maximum Wire Size
8 AWG
Wire Size
#12 AWG
Length
3.28 in
Width
1.70 in
Dimensions
3.28 in x 1.70 in x 1.31 in
Height
1.31 in
Description
In February 1968, Hubbell patented the first isolated ground receptacle. Today - when a clean, noise-free ground is more important than ever—Hubbell is still setting the standard. Hubbell uses insulation barrier construction on many models to isolate the ground contacts from the mounting strap. The green grounding screw is connected directly to the grounding contacts. In this way, ground contacts are separated from the mounting strap and also from the conventional grounding system. The isolated ground circuit is completed by running a dedicated insulated ground wire from the system ground buss to the green grounding screw.
• Insulation barrier construction isolates ground contact from mounting strap
• Wire restraint recess for both back and side wiring, greatly reduces the possibility of loosening the terminal connection
• High-impact, abuse-resistant nylon face
• All-brass mounting and grounding system provides a lower resistance ground path and greater resistance to corrosion than steel mounting systems
• Insulation barrier construction isolates ground contact from mounting strap
• Wire restraint recess for both back and side wiring, greatly reduces the possibility of loosening the terminal connection
• High-impact, abuse-resistant nylon face
• All-brass mounting and grounding system provides a lower resistance ground path and greater resistance to corrosion than steel mounting systems
