  11. Pin & Sleeve Plug, 200 A, 600V AC, Single Phase, 3 Pole, Style 2 Grounding, Black, Gray
Hubbell Wiring Device-Kellems Pin & Sleeve Plug, 200 A, 600V AC, Single Phase, 3 Pole, Style 2 Grounding, Black, Gray HBL4200PS2W - main

Pin & Sleeve Plug, 200 A, 600V AC, Single Phase, 3 Pole, Style 2 Grounding, Black, Gray

  • Mfr # HBL4200PS2W

  • Zoro # G0575386

product price: $1,358.10
/ea
Free Shipping & Returns

Key Features

Current Rating
200 A
Voltage Rating
600V AC
Phase
Single
Number of Poles
3
Number of Wires
4
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL4200PS2W
Zoro #
G0575386
UPC #
-
Country of Origin
United States

Dimensions

For Minimum Cable Diameter
1 in
Minimum Wire Size
1 AWG
Maximum Wire Size
250 kcmil
Outside Diameter
6.7 in
For Maximum Cable Diameter
2.50 in
Overall Length
11.13 in
Wire Size
#1 AWG to #250MCM
Display Size
Standard Sized

Details

Item
Pin & Sleeve Plug
Current Rating
200 A
Voltage Rating
600V AC
Phase
Single
Number of Poles
3
Number of Wires
4
IP Rating
Not Rated
Wire Connection Type
Screw Terminals
Connection Orientation
Straight
Housing Color
Black, Gray
Cap Type
No Cap or Cover
Standards
CSA C22.2 No. 159, UL Listed
Resistance Properties
Impact Resistant, Moisture Resistant, Watertight
Grounding Style
Style 2
Switch Rated
No
Features
All-Brass Sleeve Contacts Provide Reliable Electrical Contact, Catalog Number and Rating Visible While in Use, Locking Ring Provides UL Type 4X Watertight, Dust-Tight Seal
NEMA Enclosure Rating
Not Rated
Reverse Service
No
Maximum Operating Temperature
75 Degrees C
Power Indicating Light
No
Housing Material
Non-Metallic
Minimum Operating Temperature
-40 Degrees F
Market
Industrial
Shrouded
Yes
Material
Composite
Hub Style
Standard
OEM Brand Name
Hubbell Wiring Device-Kellems
Style
Standard Service,Style 2 Grounding
Series
UL 1686 Class 1 Insulgrip®
Environmental Conditions
Watertight
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 3,000V AC Electrical - Max. Working Voltage - 600V AC RMS Environmental - Flammability (Enclosure) - UL 94V-0 and CSA C22.2 No. 0.17 Environmental - Moisture Resistance - Type 3, 4, 4X per UL 50E and CSA 22.2, No. 94 Environmental - Operating Temperatures - Max. Continuous 75°C Min. -40°C w/o impact -25° with impact Mechanical - Impact Resistance - Per CSA C22.2, No. 182.1, UL 1682 Mechanical - Product Identification - Identification and ratings are permanently fastened to the device housing Mechanical - Terminal Identification - Terminals identified in accordance with UL 1686(1, 2, 3, Green)
Industry Standard(s)
CSA Certified to CSA Spec. C22.2 No. 159 UL Listed and CSA Certified Type 4X UL Standard 1682,UL 50, and UL 1010
Material - Mounting Hardware
Cord Mounted
Application
Metallic with Nylon Shroud
Cord Type
All Portable
Connection Type
Screw Terminals

Description

The HUBBELL Pin & Sleeve Plug is a watertight electrical connector intended for use in industrial settings where robust power connections are needed. It features a composite construction with metallic shrouding and a non-metallic housing, constructed to enhance durability and incorporate features that address electrical safety. This plug accommodates wire sizes from 1 AWG to 250 kcmil and supports up to 200 A at 600V AC single-phase operation.


Key Features of the HUBBELL Pin & Sleeve Plug:

  • Current/Voltage Rating: Rated for 200 A and up to 600V AC single phase

  • Construction: Composite material with metallic shroud and non-metallic housing

  • Cord Compatibility: Compatible with a range of portable cord types

  • Wire Connection Type: Pressure terminal screws support #1 AWG to #250MCM wire sizes

  • Environmental Resistance: Rated as watertight, moisture-resistant, and impact-resistant; UL Type 4X dust-tight seal via locking ring

  • Temperature Range: Operates between -40°C (min) and +75°C (max)

  • Sleeve Contacts: Features all-brass sleeve contacts

  • Certifications/Standards: CSA C22.2 No.159, UL Listed, UL Standard 1682/50/1010; meets flammability rating UL94 V-0

  • Pole/Wire Configuration: Single phase, three poles, four wires; grounded (Style 2 grounding)

  • Identification: Catalog number and ratings are visible during use; terminals identified per UL standards
