- Voltage
- 125V
- Material
- Nylon
- Type
- 2-Pole 3-Wire, Grounding
- Color
- Lightalmond
- Phase
- Single Phase
- Application
- Commercial Specification Grade
- Flammability
- UL 94 V2.
- Face Shape
- Traditional
- Horsepower
- 0.5
- Product Type
- Flush-receptacles
- Rating
- 15A, 125V
- Wiring Method
- Back and Side Wired
- Device Color
- Light Almond
- Amperage
- 15A
- Base Material
- Nylon
- Receptacle Grade
- Specification Grade Commercial Series, Tamper and Weather Resistant
- Top Material
- Nylon
- Power Contacts Material
- .030" (.8) Brass
- NEMA No.
- 5-15R
- Receptacle Style
- Duplex
- Operating Temperatures
- Maximum continuous 75°C; minimum -40°C (w/o impact)
- Other Available Colors
- Brown, Ivory, White, Office White, Almond, Light Almond, Gray, Black
- Terminal Identification
- Terminals identified in accordance with UL 498 and CSA
- Standard
- NEMA
- Terminal Accommodation
- #14-#10 AWG copper stranded or solid conductor only
- Dielectric Voltage
- Withstands 2,000V minimum
- Current Interrupting
- Certified for current interrupting at full rated current
- Mounting Strap Material
- .040" (1) Steel (Galvanized)
- Mounting Screw Material
- Steel-Zinc Plated
- Poles and Wires
- 2 Pole, 3-Wire Grounding
- Auto Ground Clip Material
- Stainless Steel
- Certification
- UL Listed to UL498 File E2186, Guide RTRT Fed Spec WC596G, Meets WD-1 Heavy Duty and WD-6 requirements, Certified to CSA, C22.2, No. 42 file 285.
- Temperature Rise
- Max 30°C temperature rise at full rated current after 50 cycles of overload at 150% of rated current
- Nema Rating
- 5-15R
- Dielectric Strength
- Withstands 2,000V minimum
- Operating Temperature
- Maximum continuous 75°C and minimum -40°C without Impact
- Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current
Electrical - Dielectric Voltage - Withstands 2,000V minimum
Environmental - Flammability - UL 94 V-2
Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact)
Mechanical - Product Identification - Ratings are a permanent part of the device
Mechanical - Terminal Accommodation - #14-#10 AWG copper stranded or solid conductor only
Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
- Connectivity
- Back and Side Wired
- Environmental Conditions
- Weather Resistant
- Material - Mounting Hardware
- Screw Mounting
- Style
- Smooth Face
- Horsepower - Maximum
- 0.5
- Number Of Wires
- 3-Wire
- Amperage Rating
- 15 A
- Voltage Rating Description
- 125 V
- Series
- Commercial Specification Grade
- Number Of Poles
- 2-Pole
- Current Rating
- 15 A
- Industry Standard(s)
- Certified to CSA C22.2, No. 42
NEMA® WD-6 Compliant
UL Listed to UL498 File No. E2186
- Current / Amperage Rating
- 15 A
- OEM Brand Name
- Hubbell Wiring Device-Kellems
- Item Type
- Traditional Duplex
- Wattage
- 1875 W
