  11. Straight Blade Plug, 14-60P, 60 A, 125/250V AC, 3 Pole, Screw Terminals, Grounded
Hubbell Wiring Device-Kellems Straight Blade Plug, 14-60P, 60 A, 125/250V AC, 3 Pole, Screw Terminals, Grounded HBL9462C - main

Straight Blade Plug, 14-60P, 60 A, 125/250V AC, 3 Pole, Screw Terminals, Grounded

  • Mfr # HBL9462C

  • Zoro # G0626202

product price: $127.44
/ea
Free Shipping & Returns

Key Features

NEMA Plug Configuration
14-60P
Phase
Single
Number of Poles
3
Number of Blades
4
Wire Connection Type
Screw Terminals
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL9462C
Zoro #
G0626202
UPC #
783585015361
Country of Origin
United States

Dimensions

For Maximum Cable Diameter
1.31 in
For Minimum Cable Diameter
0.625 in
Cord Size
0.625 in to 1.310 in
Maximum Wire Size
4 AWG
Minimum Wire Size
12 AWG
Body Length
3.38 in
Length
3.38 in
Width
4.5 in
Dimensions
3.38 in x 4.5 in x 2.37 in
Wire Size
#12 AWG to #4 AWG
Height
2.37 in

Details

Item
Straight Blade Plug
NEMA Plug Configuration
14-60P
Current Rating
60 A
Voltage Rating
125/250V AC
Phase
Single
Number of Poles
3
Number of Blades
4
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Angled
Grounding
Grounded
Housing Color
Black
IP Rating
IP20
Standards
CSA C22.2, UL 498
Resistance Properties
Corrosion Resistant
HP
2.0 Line to Neutral, 3.0 Line to Line
Special Features
Corrosion resistant
Grade - Plugs and Receptacles
Industrial
Grade
Industrial
Antimicrobial
No
NEMA Plug Configuration - Plugs and Receptacles
14-60P
Voltage
125/250VAC
Number of Wires
4
Corrosion Resistant
Yes
Material
Nylon
Phase - Plugs and Receptacles
3
Polarized
Yes
Housing Material
Nylon
Minimum Operating Temperature
-40 Degrees F
Maximum Operating Temperature
167 Degrees F
Horsepower Rating
3 hp
Insulation Material
Nylon
Market
Commercial, Industrial
Ground Screw Material
3/8" Allen Head, Plated Steel
Temp. Rise
Max 30°C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%..
Weight (Lbs.)
0.85
Ground Contact Blade Material
.075" Brass
Terminal Screw Material
Steel - Zn plated
Box Terminals Material
Copper
Operating Temp.
Maximum continuous 75°C, minimum -40°C (w/o impact).
Body Style
Angle
Blade Holder Material
Glass Reinforced PET
Retainer Material
Glass Reinforced PET
Flammability
UL 94 HB
Dielectric Strength
Withstands 2,000V minimum
Cord Clamp Material
Glass Reinforced Polyester
Contact Blades Material
.100" Brass
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
Horsepower - Maximum
3
Cord Range
0.625"-1.310"
Industry Standard(s)
UL Listed To UL 498 File E2186, Guide RTRT Fed Spec WC596G, Meets WD-6 Requirements, Certified To CSA, C22.2, No. 42 File 285
OEM Brand Name
Hubbell Wiring Device-Kellems

Description

Angle Straight Blade Plug, Connection Orientation Angled, Current Rating 60 A, Grounding Grounded, Horsepower Rating 3 hp, Housing Color Black, IP Rating IP20, NEMA Plug Configuration 14-60P, Number of Blades 4, Number of Poles 3, Phase Single, Polarized Yes, Resistance Properties Corrosion Resistant, Voltage Rating 125/250V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, For Maximum Cable Diameter 1.31 in, For Minimum Cable Diameter 0.625 in, Grade Industrial
