  11. Straight Blade Plug, 6-20P, 20 A, 250V, 2 Pole, Screw Terminals, Grounded
Hubbell Wiring Device-Kellems Straight Blade Plug, 6-20P, 20 A, 250V, 2 Pole, Screw Terminals, Grounded HBL8464V - main

Straight Blade Plug, 6-20P, 20 A, 250V, 2 Pole, Screw Terminals, Grounded

  • Mfr # HBL8464V

  • Zoro # G0790185

product price: $27.79
/ea

Key Features

NEMA Plug Configuration
6-20P
Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL8464V
Zoro #
G0790185
UPC #
783585016375
Country of Origin
United States

Dimensions

For Maximum Cable Diameter
0.66 in
For Minimum Cable Diameter
0.30 in
Cord Size
0.300 in to 0.660 in
Dimensions
1.88 in x 1.5 in x 1.13 in
Cord Dia. Range
#18AWG to #12AWG
Display Size
Standard
Wire Size
#18 AWG to #12 AWG
Minimum Wire Size
18 AWG
Body Length
1.88 in
Maximum Wire Size
12 AWG
Height
1.13 in
Width
1.5 in
Length
1.88 in

Details

Item
Straight Blade Plug
NEMA Plug Configuration
6-20P
Current Rating
20 A
Voltage Rating
250V
Phase
Single
Number of Poles
2
Number of Blades
3
Wire Connection Type
Screw Terminals
Wiring Style
Hinged
Connection Orientation
Straight
Grounding
Grounded
Housing Color
White
IP Rating
IP20
Standards
CSA C22.2, UL 498
Resistance Properties
Corrosion Resistant
Grade - Plugs and Receptacles
Hospital
NEMA Plug Configuration - Plugs and Receptacles
6-20P
Corrosion Resistant
Yes
NEMA Configuration
6-20
Material
Nylon
Voltage
250VAC
Number of Wires
3
Color
White
Grade
Hospital Grade
Antimicrobial
No
Special Features
Corrosion resistant
Phase - Plugs and Receptacles
1
HP
2.0
Type
Plug
Style
Valise
Amperage
20 A
Temp. Rating
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Series
Hospital Grade
Brand
Hubbell Wiring Device-Kellems
Nema Rating
6-20P
Carton Quantity
10
Dielectric Strength
Withstands 2,000V minimum
Maximum Horsepower
2
Connectivity
Screw Terminals
Insulation
Insulated Body
Number Of Wires
3-Wire
UL 94 Flammability Rating
HB
Maximum Operating Temperature
167 Degrees F
For Location
Indoor
Minimum Operating Temperature
-40 Degrees F
Insulation Material
Nylon
Power Indicating Lights
Without Power Indicating Lights
Housing Material Finish
Nickel Plated
Horsepower Rating
2 hp
Housing Material
Nylon
For Environment
Dry
Polarized
Yes
Body Style
Straight
Weight (Lbs.)
0.15
Flammability
UL 94 HB
Operating Temp.
Maximum continuous 75°C; minimum -40°C (w/o impact)
Connector Type
Valise
OEM Brand Name
Hubbell Wiring Device-Kellems
Industry Standard(s)
CSA Certified to C22.2 No 42 File 280C Fed. Spec. W-C-596 NEMA® WD-6 Compliant UL Listed to UL498 File No. E1706
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2000V AC minimum Environmental - Flammability - UL 94 HB Environmental - IP Suitability - IP20 Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact) Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Accommodation - #18-#12 AWG stranded copper wire only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Horsepower - Maximum
2
Cord Range
0.300"-0.660" (7.6-16.8)
Application
Hospital Grade
Temperature Rating
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Conductor Range
#18AWG to #12AWG
Material - Mounting Hardware
Cord Mounted

Description

Straight Blade Plug, Connection Orientation Straight, Current Rating 20 A, Grounding Grounded, Horsepower Rating 2 hp, Housing Color White, IP Rating IP20, NEMA Plug Configuration 6-20P, Number of Blades 3, Number of Poles 2, Phase Single, Polarized Yes, Resistance Properties Corrosion Resistant, UL 94 Flammability Rating HB, Voltage Rating 250V AC, Wire Connection Type Screw Terminals, Wiring Style Hinged, For Maximum Cable Diameter 0.66 in, For Minimum Cable Diameter 0.3 in
