  11. Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Surface Mount, Grounded
Hubbell Wiring Device-Kellems Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Surface Mount, Grounded HBL420H - main

Straight Blade Receptacle, 5-20R, 20 A, 125V AC, 2 Pole, 3 Wire, Surface Mount, Grounded

  • Mfr # HBL420H

  • Zoro # G2278771

product price: $41.51
/ea

Key Features

Receptacle Type
Quad
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL420H
Zoro #
G2278771
UPC #
783585016146
Country of Origin
United States

Dimensions

Width
4.3 in
Height
0.92 in
Face Plate Height
4.3 in
Face Plate Width
4.3 in
Mount Hole Center-to-Center Width
3.4 in
Maximum Wire Size
12 AWG
Mount Hole Center-to-Center Height
3.4 in
Overall Depth
0.9 in
Display Size
Standard Sized Product
Dimensions
4.3 in x 4.3 in x 0.92 in
Wire Size
#12 AWG
Length
4.3 in

Details

Item
Straight Blade Receptacle
Receptacle Type
Quad
NEMA Receptacle Configuration
5-20R
Current Rating
20 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back
Grounding
Grounded
Housing Color
Brown
Mount Type
Surface
Standards
CSA Certified C22.2 No. 42 File 285, NEMA WD-6, UL 498 File E2186
Resistance Properties
Impact Resistant
Flange Type
Non-Flanged
Voltage
125VAC
NEMA Receptacle Configuration - Plugs and Receptacles
5-20R
Power Indicator
No
Number of Gangs
2
Material
polycarbonate
Mounting Type
Surface
Weather Resistant
No
HP
1 hp
Outlet Type - Plugs and Receptacles
Quad
Outlet Type
Quad
Sub-Category
Four Outlet Receptacles
Mounting Type - Plugs and Receptacles
Surface
NEMA Configuration
5-20
Wiring Method - Plugs and Receptacles
Back
Surge Suppression
No
Corrosion Resistant
No
Application Environment
Hospital Grade
Tamper Resistant
No
Weather Resistant - Plugs and Receptacles
No
Polarized
Yes
Contact Material
Brass
Maximum Operating Temperature
167 Degrees F
AFCI
No
Minimum Operating Temperature
-40 Degrees F
GFCI
No
Surge Protection
No
Cover Type
No Cover
Grade
Hospital Grade Fed. Spec.
Includes
4-PLEX Adapter Plate, 4-PLEX Portable Box
Housing Material
Polycarbonate
NEMA Enclosure Rating
1
Shrouded
No
Number of Outlets
4
Connection Orientation
Straight
Horsepower Rating
1 hp
For Location
Indoor
UL 94 Flammability Rating
V-2
Flammability
UL 94V-2
Terminal Identification
Terminals identified in accordance with UL 498 and CSA
Current Interrupting
Capable of withstanding a fault level of 1000A, per UL498
Poles and Wires
2 Pole, 3 Wire
Dielectric Voltage
Withstands 2,000V minimum
Operating Temperatures
Maximum continuous 75°C; minimum -40°C (w/o impact)
Terminal Accommodation
#12 AWG copper stranded or solid conductor only
Device Color
Brown
Nema Rating
5-20R
Dielectric Strength
Withstands 2,000V minimum
Industry Standard(s)
Certified to CSA, C22.2, No. 42 File 285 NEMA® WD-6 Compliant UL Listed to UL498 File No. E2186
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Style
Smooth Face
Performance
Electrical - Current Interrupting - Capable of withstanding a fault level of 1000A, per UL498 Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94V-2 Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact) Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Accommodation - #12 AWG copper stranded or solid conductor only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
Wattage
2500 W
Series
4-PLEX Receptacle
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
Material - Mounting Hardware
Screw Mounting
OEM Brand Name
Hubbell Wiring Device-Kellems
Horsepower - Maximum
1
Application
4-Plex Hospital Grade

Description

• Anchor hole and loop feature secures solid wire for fast, easy terminations
• Triple wipe contacts
• Easily accessible break-off tabs for split wiring
• Three conductors energize all four outlets
