  11. Straight Blade Receptacle, 5-30R, 30 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded
Hubbell Wiring Device-Kellems Straight Blade Receptacle, 5-30R, 30 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded HBL9308 - main

Straight Blade Receptacle, 5-30R, 30 A, 125V AC, 2 Pole, 3 Wire, Flush Mount, Grounded

  • Mfr # HBL9308

  • Zoro # G2949116

product price: $34.63
/ea

Key Features

Receptacle Type
Single
NEMA Receptacle Configuration
5-30R
Current Rating
30 A
Phase
Single
Number of Poles
2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HBL9308
Zoro #
G2949116
UPC #
783585015217
Country of Origin
United States

Dimensions

Width
2.23 in
Minimum Wire Size
12 AWG
Mount Hole Center-to-Center Width
1.8 in
Mount Hole Center-to-Center Height
3.3 in
Maximum Wire Size
4 AWG
Overall Depth
2.2 in
Face Diameter
2.1 in
Wire Size
#12 AWG to #4 AWG
Display Size
Standard Sized Product

Details

Item
Straight Blade Receptacle
Receptacle Type
Single
NEMA Receptacle Configuration
5-30R
Current Rating
30 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Method
Back, Side
Grounding
Grounded
Housing Color
Black
Mount Type
Flush
IP Rating
IP20
Standards
CSA, Fed Spec, UL
Resistance Properties
Corrosion Resistant
Flange Type
Non-Flanged
NEMA Receptacle Configuration - Plugs and Receptacles
5-30R
Sub-Category
Single Receptacles
Weather Resistant - Plugs and Receptacles
No
Application Environment
Industrial
Number of Gangs
1
Power Indicator
No
Surge Suppression
No
Corrosion Resistant
No
Outlet Type
Single
Weather Resistant
No
Mounting Type - Plugs and Receptacles
Flush
Mounting Type
Flush
Wiring Method - Plugs and Receptacles
Back and Side
Voltage
125VAC
Material
Phenolic
Tamper Resistant
No
HP
2 hp
Boot Code
C
Outlet Type - Plugs and Receptacles
Single
Type
Receptacle Straight Blade
AFCI
No
GFCI
No
Minimum Operating Temperature
-40 Degrees F
Housing Material
Reinforced Thermoplastic Polyester
UL 94 Flammability Rating
V-0
Cover Type
No Cover
Market
Industrial
Contact Material
Brass
Grade
Federal Specification
Includes
Mounting Hardware
Connection Orientation
Straight
For Location
Indoor
Horsepower Rating
2 hp
Polarized
Yes
NEMA Enclosure Rating
1
Maximum Operating Temperature
167 Degrees F
Shrouded
No
Surge Protection
No
Includes Mounting Hardware
Yes
Mounting Screw Material
Steel-Zinc Plated
Top Material
Phenolic
Terminal Screw Material
Plated Steel
Face Shape
Traditional
Terminal Identification
Terminals identified in accordance with UL 498 and CSA
Poles and Wires
2 Pole, 3-Wire Grounding
Base Material
Phenolic
Horsepower
2
Flammability
UL 94 V-0
Operating Temperatures
Maximum continuous 75°C; minimum -40°C (w/o impact)
Device Color
Black
Receptacle Style
Single
Dielectric Voltage
Withstands 2,000V minimum
Rating
30A, 125V
Face Style
Finder Groove
Terminal Accommodation
#12 AWG through #4 AWG copper wire only
IP Suitability
IP20
Ground Screw Material
Plated Steel
Certification
UL, CSA, Fed Spec
Mounting Strap Material
.062" (1.5) Plated Steel
Temperature Rise
Max 30°C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%..
Current Interrupting
Certified for current interrupting at full rated current
Receptacle Grade
Heavy Duty Spec Grade
Box Terminals Material
Brass
Power Contacts Material
Brass
Standard
NEMA
Industry Standard(s)
CSA Certified NEMA® WD-6 Compliant UL Listed File E2186
Dielectric Strength
Withstands 2,000V minimum
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Material - Mounting Hardware
Screw Mounting
Nema Rating
5-30R
OEM Brand Name
Hubbell Wiring Device-Kellems
Performance
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 2,000V minimum Environmental - Flammability - UL 94 V-0 Environmental - IP Suitability - IP20 Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact) Mechanical - Product Identification - Ratings are a permanent part of the device Mechanical - Terminal Accommodation - #12 AWG through #4 AWG copper wire only Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
Wattage
3750 W
Application
Heavy Duty
Horsepower - Maximum
2
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact

Description

Receptacle, Connection Orientation Straight, Cover Type No Cover, Current Rating 30 A, GFCI No, Grounding Grounded, Housing Color Black, Housing Material Reinforced Thermoplastic Polyester, Mount Type Flush, NEMA Enclosure Rating 1, NEMA Receptacle Configuration 5-30R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized Yes, Receptacle Type Single, Standards CSA Certified, NEMA WD-6, UL E2186, Voltage Rating 125V AC, Wire Connection Type Screw Terminals
