  6. Switches and Lighting Controls, Illuminated Industrial Grade, PresSwitch, General Purpose AC, Four Way, 15A 120/277V AC, Screw Terminals, Ivory
Hubbell Wiring Device-Kellems Switches and Lighting Controls, Illuminated Industrial Grade, PresSwitch, General Purpose AC, Four Way, 15A 120/277V AC, Screw Terminals, Ivory HBL1259I - main

Switches and Lighting Controls, Illuminated Industrial Grade, PresSwitch, General Purpose AC, Four Way, 15A 120/277V AC, Screw Terminals, Ivory

  • Mfr # HBL1259I

  • Zoro # G100701675

product price:  $137.70
/ea
Free Shipping & Returns

Key Features

Switch Type
Illuminated Four Way
Color
Ivory
Style
Four Way
Voltage
120V AC
Height
1.45 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
HBL1259I
Zoro #
G100701675
UPC #
783585016801
Country of Origin
United States

Dimensions

Height
1.45 in
Width
1.5 in
Length
3.28 in
Dimensions
3.28 in x 1.5 in x 1.45 in
Wire Size
#14 AWG to #10 AWG

Details

Item
Four Way Toggle Switch
Switch Type
Illuminated Four Way
Color
Ivory
Style
Four Way
Voltage
120V AC
Current Rating
15 A
Temp. Rise
30°C maximum at rated current
Connectivity
Side Wired Only
Indicator
Light On with Load Off
Action
DPDT
Series
Illuminated
Amperage
15 A
Voltage Rating
120 VAC
Dielectric Strength
Withstands 1500V AC minimum for 1 minute
Number Of Poles
Single Pole
Carton Quantity
10
Operating Temperature
Max. continuous: 75°C; Min. continuous: -40°C without impact
Max. Working Voltage
277V AC
Dielectric Voltage
Withstands 1500V AC minimum for 1 minute
Listing and Certifications
UL Listed and CSA Certified
Overload
Minimum 4.8 times rated current for 100 cycles
Toggle Color
Ivory
Wiring Style
Side Wired Only
Product Type
Toggle-switches
Switch Grade
PresSwitches
Temperature Rise
30°C maximum at rated current
Max. Continuous Current
15A
Switch Handle Positions
2
Flammability
UL 94V-2
Terminal Accommodations
#14 AWG min. - #10 AWG max. solid and stranded copper wire only
Operating Temperatures
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Performance
Electrical - Dielectric Voltage - Withstands 1500V AC minimum for 1 minute Electrical - Max. Continuous Current - 20A Electrical - Max. Working Voltage - 277V AC Electrical - Overload - Minimum 4.8 times rated current for 100 cycles Electrical - Temperature Rise - 30°C maximum at rated current Environmental - Flammability - UL 94V-2 Environmental - Operating Temperature - Max. continuous: 75°C, Min. continuous: -40°C without impact Mechanical - Terminal Accommodations - #14 AWG min. - #10 AWG max. solid and stranded copper wire only
Voltage Rating Description
120 VAC
Amperage Rating
15 A
Industry Standard(s)
Fed. Spec. W-S-896
Item Type
Four Way Toggle Switch
Temperature Rise - Max.
30°C maximum at rated current
Current / Amperage Rating
15 A

Description

Hubbell Wiring Device Kellems, Switches and Lighting Controls,Illuminated Industrial Grade, PresSwitch, General Purpose AC, SinglePole, 15A 120/277V AC, Screw Terminals , Ivory
