Contact our U.S. based teamSpecifications
Product Information
MFR #
IC107F6RBL
Zoro #
G109851104
UPC #
633758093910
Country of Origin
Taiwan, Province of China
Details
Color
Transparent Red, Blue
Contact Resistance
20 mohms max
Termination Cap
PC, UL 94V-0
Current rating
1.5 amps
Jack Wiring
50 Micro Inches of Gold over 100 Micro Inches of Nickel
Plug Insertion Life
750 cycles min
Jack Style
HD
Plug and Jack Contact Force
100 grams min
Performance
CAT6
DC Resistance
0.1-ohm max
Temperature
-40° to 150° F (-40° to 68° C)
Plug Retention Force
30 lbs min
Connector
Insulation Displacement Connection (IDC), 8P8C
Housing
ABS, UL 94V-0
Insulation Resistance
500 mohms min
Product Type
Keystone Jacks
Description
CAT6 rated connectors provide excellent performance for data networks- PCB technology provides maximum performance and superior signal quality- Enhanced crosstalk cancellation reduces return loss and improves performance- Rejecting noise and unwanted signals- Exceeds ANSI/TIA-568-C.2 Category 6 connecting hardware requirements- Designed with rear split back 110 IDC reducing termination time- Terminate with 110 punch down tool- Reduced rear footprint allows for greater connectivity density- Provides for more port configurations in a smaller area- Includes an integrated TIA-568A/B color wiring diagram- Backward compatible with all lower rated category components- Works with all Work Area Outlets faceplates, inserts, surface mount boxes- Used with Category 6 patch cords- Exceeds ANSI/TIA-568-C requirements for permanent performances- UL 1863 Compliant
