Contact our U.S. based teamSpecifications
Product Information
MFR #
IC1078S6A0
Zoro #
G709851047
UPC #
633758029315
Country of Origin
Taiwan, Province of China
Details
Wire Cap
Zinc-Alloy
Dielectric Withstanding Voltage
1,000 volts D.C., 60 Hz, 1 min
Insulation Resistance
500 mega ohm min
Jack Style
HD
Relative Humidity (Operational)
Maximum Noncondensing 93%
IDC Wire Gauge
22-24 AWG Solid Wire
Connector
8P8C
Housing
Zinc-Alloy Fully Shielded
Insertion Life
750 cycles min
Product Type
Keystone Jacks
Performance
CAT6A
Total Contact Force
800 gram for 8 wires leads minimum
Retention
50N (11 lbf) for 60S±5S
Spring Wire
Phosphor Bronze Alloy Plated with 50 micro-inch of gold over 70-100 micro-inch of nickel
Contact Resistance
20 milliohm max
Description
ICC Cat 6A Shielded Modular Keystone Jack- Foiled Twisted Pair FTP CAT 6A rated connectors provide excellent performance for data networks requiring maximum speed and bandwidth- Lead frame technology provides maximum performance and uninterruptible signal integrity- Enhanced crosstalk cancellation reduces return loss and improves performance by rejecting noise and unwanted signals- Exceeds TIA 568-B.2-10 Category 6A connection hardware requirements- One piece termination cap allows for a quick and easy termination- Provide shielding against electro-magnetic interference EMI- Includes an integrated TIA-568A/B color wiring diagram- UL Listed
