  11. Cylindrical, Inductive Proximity Sensor, 30 mm Dia., Brass, 2 m, Bare Wire, 3 Wires, Shielded
Ifm Cylindrical, Inductive Proximity Sensor, 30 mm Dia., Brass, 2 m, Bare Wire, 3 Wires, Shielded IIS244 - main

Cylindrical, Inductive Proximity Sensor, 30 mm Dia., Brass, 2 m, Bare Wire, 3 Wires, Shielded

  • Mfr # IIS244

  • Zoro # G0395300

product price: $71.19
/ea

Key Features

Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
10 to 30V DC
Length
40 mm
Proximity Sensor Electrical Connection
2m Cable
Proximity Sensor Operating Frequency
100 Hz
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
IIS244
Zoro #
G0395300
UPC #
-
Country of Origin
Germany

Dimensions

Length
40 mm
Cable Length
2 m
Overall Height
45 mm
Overall Diameter
30 mm

Details

Item
Proximity Sensor
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
10 to 30V DC
Proximity Sensor Electrical Connection
2m Cable
Proximity Sensor Operating Frequency
100 Hz
Description/Special Features
Overload And Short Protection
Max. Current Load
100mA
IP Rating
IP65, IP66, IP67, IP68, IP69K
Operating Temp. Range
-40 Degrees to 185 Degrees F
Standards
EN 61000-4-2 ESD, EN 55011, EN 60068-2-14 Na, EN 60068-2-27, EN 60068-2-27 Ea, EN 60068-2-52 Kb, EN 60068-2-6 FC, EN 61000-4-3 HF Radiated, EN 61000-4-4 Burst, EN 61000-4-6 HF Conducted, UL E174191, UL A002
Includes
(2) Lock Nuts
Electrical Connection
Bare Wire
Operating Temperature - Maximum
185 Degrees F
Sensing Face Shielding
Shielded
Includes Indicator Lights
Indicator Lights Included
Electrical Installation Type
Prewired Cable
Output Circuit Voltage - Maximum
2.5 V DC
AC Voltage Rating
Not Rated
Output Circuit Type
NPN
Body Finish
Bronze Coated
Switching Frequency
100 Hz
Operating Temperature - Minimum
-40 Degrees F
Style
Cylindrical, Inductive
Sensing Distance - Maximum
15 mm
Features
Safe Detection
Output Circuit Number of Wires
3
Output Circuit Contact Form
NO
DC Voltage Rating
10-30V DC
Body Material
Brass
Output Circuit Current - Maximum
100 mA

Description

Inductive Cylindrical Proximity Sensor, Inductive, 30 mm, Proximity Sensor Power Requirement 10 to 30V DC, Shielded, Proximity Sensor Operating Frequency 100 Hz, Proximity Sensor Output Circuit Type 3 Wire NPN, Max. Detecting Distance 15 mm, Proximity Sensor Electrical Connection 2m Cable, Output Mode NO, IP Rating IP65, IP66, IP67, IP68, IP69K, Case Material Brass White Bronze Coated, Length 40 mm, Operating Temp. Range -40 Degrees to 185 Degrees F, Max. Current Load 100mA
