Ifm Temperature Sensor TM4341 - main

Temperature Sensor

  • Mfr # TM4341

  • Zoro # G7052787

product price: $134.99
/ea
Free Shipping & Returns

Key Features

Sensor Type
RTD
Width (In.)
1 3/50 in
Height (In.)
1 69/100 in
Nominal Sensor Ohms @ 75F
109.5
Length (In.)
5 59/100 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
TM4341
Zoro #
G7052787
UPC #
-
Country of Origin
United States

Dimensions

Width (In.)
1 3/50 in
Height (In.)
1 69/100 in
Length (In.)
5 59/100 in
Overall Height
1 1/16 in
Overall Depth
1 1/16 in
Overall Length
7 5/16 in
Probe Length
5 5/8 in
Probe Diameter
1/4 in

Details

Item
Temperature Sensor
Sensor Type
RTD
Nominal Sensor Ohms @ 75F
109.5
Operating Temp. Range (F)
-40 Degrees to 302 Degrees
Thread NPT
1/2 in
Function
Temperature Sensor
Compatible Brand and Series
IFM Efector
Accessory Type
Temperature Sensor
Compatible Manufacturer Model Number
TP3231, TP3232, TP3233, TP3237, TP9237
Standards
CE Certified, cULus Listed, EAC
NEMA Rating
6P
Temperature Accuracy
+/- 0.15 K
Minimum Operating Temperature
-25 Degrees F
Sensing Element Type
Platinum
Housing Type
Standard Housing
Loop Resistance
100 ohm
Housing Material
Stainless Steel
Measurement Type
Single
Housing Color
Metallic
Electrical Connection Type
Plug-In
IP Rating
IP68, IP69K
Sensor Accuracy
+/-0.15 K
Product Type
Temperature Sensor
Maximum Operating Temperature
80 Degrees F
Weight
0.42 lb
Display Type
None
Minimum Sensing Temperature
-40 Degrees F
Application
Temperature Monitoring
Housing Material Finish
Gold Plated
Maximum Sensing Temperature
302 Degrees F
For Use With Building Automation Systems
Building Automation System Compatible

Description

Temperature Sensor, Display Type None, Sensing Element Type Platinum, Output Not Applicable, Housing Type Standard Housing, Housing Material Stainless Steel, Housing Color Metallic, Probe Length 5 5/8 in, Temperature Accuracy +/- 0.15 K, Electrical Connection Type Plug-In, Product Type Temperature Sensor, Maximum Sensing Temperature 302 Degrees F, Minimum Sensing Temperature -40 Degrees F, For Use With Building Automation Systems Building Automation System Compatible
