Shop INTERMATIC

Hour Meter, 24VAC, 60 Hz, DIN Rail Mount

  • Mfr # UWZ48V-24U

  • Zoro # G7166573

product price:  $92.79
/ea

Key Features

Display Type
Electromechanical
Mounting Type
DIN Rail
Reset Type
No Reset
Display Units
Hours/Hundredths
Number of Digits
7
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
UWZ48V-24U
Zoro #
G7166573
UPC #
614573213301
Country of Origin
Mexico

Dimensions

Bezel Face Size
1.88 in x 1.88 in
Length
2.44 in
Depth
2.36 in
Width
1.89 in
Bezel To Back Length
2.36 in
Length (Straight Wireway)
2.44 in
Character Height
0.16 in, 4.1 mm
Height
2.44 in, 62 mm
Product Width (in)
1.89
Product Depth (in)
2.36
Product Height (in)
2.44
Overall Width
1 7/8 in
Overall Height
2 1/2 in
Overall Depth
2 3/8 in
Bezel Face Width
1 7/8 in
Bezel Face Height
1 7/8 in

Details

Item
Hour Meter
Display Type
Electromechanical
Mounting Type
DIN Rail
Reset Type
No Reset
Display Units
Hours/Hundredths
Number of Digits
7
Operating Voltage
24V AC
Time Range
0 to 99999.99
Bezel Face Shape
Square
Bezel Face Type
Flush Mount
Material of Construction
Plastic
Input Type
Electrical
Elapsed Time To
99,999.99
Hz
60 Hz
Terminal Type
Screw
Temp. Range
-40 Degrees to 160 Degrees F
Mounting Method
DIN Rail
NEMA Rating
1
Ambient Temp. Range
-40 Degrees to 160 Degrees F
For Use With
Commercial, Industrial
Power Required
1 VA
IP Rating
IP20
Standards
cCSAus, CE, RoHS, RU
Wiring Option
Combination 1/4" spade and screw clamp
Mounting Options
DIN Rail
Input Voltage Range(s)
24 VAC, 60 Hz
Digits Coloring (Hours)
White on Black
Environmental Rating
IP20
Digits Coloring (Tenths)
Yellow on Black
Operating Temperature Max (°F)
160
Applications
Distribution/Control Panel Monitoring
Mechanism Type
Electromechanical
Color
Light Gray
Mechanical Movement
Synchronous
Hour Meter Material
Plastic
Operating Temperature Min (°F)
-40
Operating Temperature Max (°F)
160
Operating Temperature Min (°F)
-40
NEMA Enclosure Rating
1
Input Voltage - Maximum
24 V AC
Display Span - Maximum
99,999.99
Mounting Style
Flush
Operating Temperature - Maximum
160 Degrees F
Mount Securing Method
DIN Rail
Counter Display Type
Analog
Operating Temperature - Minimum
-40 Degrees F
Hour Unit Increment
Hundreth

Description

Hour Meter, Display Type Electromechanical, Time Range 0 to 99999.99, Bezel Face Size 1.88 in x 1.88 in, Bezel Face Shape Square, Bezel Face Type Flush Mount, Elapsed Time To 99,999.99, Operating Voltage 24V AC, Hz 60 Hz, Number of Digits 7, Display Units Hours/Hundredths, Bezel To Back Length 2.36 in, Depth 2.36 in, Length 2.44 in, Width 1.89 in, Ambient Temp. Range -40 Degrees to 160 Degrees F, NEMA Rating 1, Material of Construction Plastic, Input Type Electrical, Reset Type No Reset
