  11. Surge Protection Device, 1 Phase, 120/240V, 3 Wires, 50 kA
Intermatic Surge Protection Device, 1 Phase, 120/240V, 3 Wires, 50 kA AG2401C3 - main

Surge Protection Device, 1 Phase, 120/240V, 3 Wires, 50 kA

  • Mfr # AG2401C3

  • Zoro # G2124545

product price: $108.99
/ea
Sold in multiples of 6 for $653.94
Free Shipping & Returns

Key Features

Phase
1
Voltage
120/240V
Voltage Protection Rating
1200V (L-L), 700V (L-G, N-G)
Number of Wires
3 Wires
Max. Surge Current per Mode
50 kA
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
AG2401C3
Zoro #
G2124545
UPC #
078275124431
Country of Origin
Mexico

Dimensions

Depth
4 3/16 in
Wire Lead Length
18 in; 457.2 mm
Product Diameter
3 in; 76.2 mm
Wire Size Max
#12 AWG

Details

Item
Surge Protection Device
Phase
1
Voltage
120/240V
Voltage Protection Rating
1200V (L-L), 700V (L-G, N-G)
Number of Wires
3 Wires
Max. Surge Current per Mode
50 kA
Max. Surge Current per Phase
50 kA
Nominal Discharge Current
20 kA
Short Circuit Current Rating
50kA
Enclosure NEMA Rating
NEMA 4X
Features
Six modes of protection; TPMOV® surge protection technology; Green LED protection indicator; Type 4X watertight, plastic enclosure for outdoor installations; UV-resistant polycarbonate housing; 1â„2" threaded nipple for 7â„8" nominal conduit knockout; 1-year product warranty; CSA certified to ANSI/UL 1449 5th edition
Includes Surge Counter
No
Units Per Pallet
720
Maximum Continuous Operating Voltage LN
150
Market
Commercial; Industrial; Residential
UL Certification
UL
Surge Protection Technology
TPMOV®
CSA Certification
CSA; cCSAus; cCSAus SPD Type 1; cCSAus SPD Type 2
Solutions
Surge Protection
Applications
Distribution Panel; Service Entrance
Voltage Protection Rating LG
700
Maximum Continuous Operating Voltage LL
300
LED Surge Protection Indicator
Green
Wiring Option
Wire leads
Maximum Continuous Operating Voltage L1 L2
300
Operating Temperature Min
-31°C
Operating Temperature Max
185°C
Modes Of Protection
3 (L1-N, L2-N, L1-L2)
Surge Protection Types
1; 2
Maximum Continuous Operating Voltage LG
150
Packaging Applications
Light Commercial; Outdoor Applications; 3-Phase Rooftop HVAC Units
Surge Protection LED Indicator
Green
Operating Temperature Min (°F)
-31
Operating Temperature Max (°F)
185
Surge Protection Type
1, 2
Maximum Continuous Operating Voltage (L-G)
150
Maximum Continuous Operating Voltage (L-L)
300
UL Standard
ANSI/UL 1449 5th Edition
Maximum Continuous Operating Voltage (L1-L2)
300
Maximum Continuous Operating Voltage (L-N)
150
Operating Temperature Max (°F)
185
Operating Temperature Min (°F)
-31
Enclosure Material
plastic

Description

Type 1/Type 2 Surge Protective Device
