Shop INTERMATIC

Timer, Digital, 120V, 12A, Wall Switch

  • Mfr # EJ600
  • Zoro # G6787672
product price:
$
72.49
/ea

Key Features

Voltage
120V AC
Max. Time Setting
59 min, 23 hr, 6 days
Min. Time Setting
1 min
Max. On/Off Cycles
7
Color
White
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
EJ600
Zoro #
G6787672
UPC #
078275127876
Country of Origin
China

Dimensions

Length
3 in
Width
2 3/32 in
Depth
2 3/32 in
Length (Straight Wireway)
3 in
Product Depth (in)
1.4375
Product Height (in)
4.125
Product Width (in)
1.75
Overall Depth
1 7/16 in
Overall Width
1 3/4 in
Overall Height
4 1/8 in
Fits Chest Size
Built-in Rechargeable, Incandescent/fluorescent Compatible, Non-serviceable Battery Backup

Details

Item
Wall Switch Timer
Voltage
120V AC
Max. Time Setting
59 min, 23 hr, 6 days
Min. Time Setting
1 min
Max. On/Off Cycles
7
Color
White
Watts
1800
HP @ 120V
1/4 hp
Number of Gangs
1
Amps
12
Type of Switch
Electronic
Standards
cCSAus
Features
Built-in Rechargeable, Incandescent/fluorescent Compatible, Non-serviceable Battery Backup
Switch Type
3-Way
Style
Wall Switch
Battery Type
Lithium Rechargeable
Number of Poles
1
Green Environmental Attribute
Product is Rechargeable
Product Type
Wall Switch Timers
Backup Type
Battery
Tungsten Incandescent
1440 W, multi-gang, 1800 W, single-gang
Motor Load Ratings Ranges
1/2 HP
Maximum ON/OFF Operations
14
Backup Protection Time
100 Hours
Application Compatibilities
Fluorescent, Incandescent
Input Voltage Range(s)
120 VAC, 60 Hz
Neutral Connection Required
Yes
Mechanism Type
Digital/Electrical
Operation Features
Astronomic, Daylight Saving Time
Applications
Air Movement & Ventilation Indoor Lighting Control Outdoor Lighting Control
Includes Wall Plate
No Wall Plate Included
Tungsten (Incandescent) Range(s)
1440 W, multi-gang, 1800 W, single-gang
Inductive
500 VA, 120 VAC, 60 Hz
Inductive Load Ratings Ranges
500 VA, 120 VAC, 60 Hz
Battery Service Type
Non-Serviceable
Wiring Configurations
3-Way, Single
Operating Temperature Min (°F)
32
Ballast Fluorescent
4 A, 500 VA
Operating Temperature Max (°F)
104
Resistive Heater
12 A, 1440 W
Minimum ON/OFF Times
1 min
Operation Mode
24 hour
Wall Plate Configurations
Single-Gang
Contact Form
SPST-NO
Operating Temperature Max (°F)
104
Operating Temperature Min (°F)
32
On/Off Cycles - Maximum
7
AC Voltage Rating
120V AC
Display Type
Digital
Switch Style
3-Way
Compatible Lighting
Fluorescent, Incandescent, LED
Wattage - Maximum
1,440 W
Time Setting - Maximum
7 day
Time Setting - Minimum
1 min
Indoor/Outdoor Usage
Indoor, Outdoor
Application
HVAC, Lighting
Includes Hold
No Hold Included
Body Color
White
Horsepower @ 120V - Maximum
1/2 hp
Current Rating - Maximum
12 A

Description

Wall Switch Timer, Min. Time Setting 1 min, Max. Time Setting 59 min, 23 hr, 6 day, Max. On/Off Cycles 7, Voltage 120V AC, Watts 1800, Amps 12, 3-Way, HP @ 120V 1/4 hp, Type of Switch Electronic, Color White, Length 3 in, Width 2 3/32 in, Style Wall Switch, Depth 2 3/32 in, Number of Gangs 1, Battery Type Lithium Rechargeable, Features Built-in Rechargeable, Incandescent/fluorescent Compatible, Non-serviceable Battery Backup, Standards cCSAus
