Pillow Block Ball Bearing Mounted Unit, Cast Iron Housing Material, 3 in Dia
Mfr # NAP215-48
Zoro # G023389974
product price:Â
$
332.99
/ea
Free Shipping & Returns
Key Features
Shaft Locking Type
Eccentric Collar
Housing Material
Cast Iron
Bearing Material
AISI 52100
Bore Diameter
3 in
Closure
Double Sealed
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- NAP215-48
- Zoro #
- G023389974
- UPC #
- 080067569441
- Country of Origin
- China
- Item
- Pillow Block Ball Bearing Mounted Unit
- Shaft Locking Type
- Eccentric Collar
- Housing Material
- Cast Iron
- Bearing Material
- AISI 52100
- Closure
- Double Sealed
- Standards
- AFBMA
- Lubricant Material
- NLGI #2 Equivalent
- Maximum Temperature
- 248 Degrees F
- Features
- Wide Inner Ring Bearing
- Expansion Type
- Fixed
- Bearing Lubrication
- Relubricateable
- Bearing Insert Material
- Alloy Steel
- Minimum Temperature
- -4 Degrees F
- Maximum Speed
- 2,100 RPM Grease
- Included Bearing
- NA215-48
- System of Measurement
- Inch
- Lubrication Openings
- Grease Fitting
- Includes
- Grease Zerk
- Static Radial Load Capacity
- 10,540 lbf
- Bearing Material Grade
- AISI 52100
- Split Housing
- Not Split
- Number of Mount Holes
- 2
- Series
- Eccentric Collar Locking Pillow Block
- Dynamic Radial Load Capacity
- 14,620 lbf
Description
Pillow Block Bearing, Bearing Insert Material Alloy Steel, Bearing Insert Type Ball, Bore Diameter 3 in, Center Height 3 1/4 in, Closure Double Sealed, Expansion Type Fixed, Housing Material Cast Iron, Included Bearing NA215-48, Lubricant Material NLGI #2 Equivalent, Maximum Speed 2,100 RPM Grease, Maximum Temperature 248 Degrees F, Minimum Temperature -4 Degrees F, Mount Hole Center-to-Center Length 217 mm, Number of Mount Holes 2, Overall Height 166 mm, Overall Length 275 mm
