Pillow Block Ball Bearing Mounted Unit
Mfr # SAP205-15G
Zoro # G723388505
product price:Â
$
41.75
/ea
Key Features
Overall Width
38 mm
Number of Mount Holes
2
Overall Height
72 mm
Includes
Grease Zerk
Closure
Double Sealed
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- SAP205-15G
- Zoro #
- G723388505
- UPC #
- 080067570728
- Country of Origin
- China
- Item
- Pillow Block Ball Bearing Mounted Unit
- Number of Mount Holes
- 2
- Includes
- Grease Zerk
- Closure
- Double Sealed
- Maximum Speed
- 5,850 RPM Grease
- Features
- Narrow Inner Ring Bearing
- Bearing Material Grade
- AISI 52100
- Bearing Insert Material
- Alloy Steel
- Split Housing
- Not Split
- Static Radial Load Capacity
- 1,750 lbf
- Bearing Lubrication
- Relubricateable
- Dynamic Radial Load Capacity
- 3,010 lbf
- Lubricant Material
- NLGI #2 Equivalent
- Series
- SAP
- Minimum Temperature
- -4 Degrees F
- Expansion Type
- Fixed
- Shaft Locking Type
- Eccentric Collar
- Standards
- AFBMA
- Housing Material
- Cast Iron
- Maximum Temperature
- 248 Degrees F
- System of Measurement
- Inch
- Lubrication Openings
- Grease Fitting
- Included Bearing
- SA205-15G
Description
Pillow Block Bearing, Bearing Insert Material Alloy Steel, Bearing Insert Type Ball, Bore Diameter 15/16 in, Center Height 1 7/16 in, Closure Double Sealed, Expansion Type Fixed, Housing Material Cast Iron, Included Bearing SA205-15G, Lubricant Material NLGI #2 Equivalent, Maximum Speed 5,850 RPM Grease, Maximum Temperature 248 Degrees F, Minimum Temperature -4 Degrees F, Mount Hole Center-to-Center Length 105 mm, Number of Mount Holes 2, Overall Height 72 mm, Overall Length 140 mm
