Piloted Flange Ball Bearing Mounted Unit
Mfr # UCFCF205-14
Zoro # G023388304
product price:Â $44.85
/eaKey Features
Shaft Locking Type
Set Screw
Housing Material
Cast Iron
Bore Diameter
0.875 in
Overall Width
31 mm
Temp. Range
248 Degrees F Max
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- UCFCF205-14
- Zoro #
- G023388304
- UPC #
- 080067570722
- Country of Origin
- China
Dimensions
- Bore Diameter
- 0.875 in
- Overall Width
- 31 mm
- Inner Ring Width
- 1.338 in
- Flange Thickness
- 10 mm
- Overall Length
- 111 mm
- Overall Diameter
- 111 mm
- Overall Height
- 111 mm
- Bolt Circle Diameter
- 10.3 mm
- Pilot Diameter
- 76.2 mm
- Mounting Bolt Size
- 5/16, M8
- Mount Hole Center-to-Center Length
- 92.1 mm
Description
Flange Mount Bearing, Bearing Insert Material Alloy Steel, Bearing Insert Type Radial Ball, Bore Diameter 7/8 in, Bore Type Cylindrical, Center Height Not Applicable, Closure Double Sealed, Expansion Type Fixed, Housing Material Cast Iron, Housing Type Circular, Included Bearing UC205-14, Lubricant Material NLGI #2 Equivalent, Maximum Speed 5,850 RPM Grease, Maximum Temperature 248 Degrees F, Minimum Temperature -4 Degrees F, Mount Hole Center-to-Center Height Not Applicable
